Correlations - Mircom TX3 Series Configuration Manual

5.
2.9

Correlations

Correlations establish specific relationships between inputs (events) and outputs
(actions) on different panels across the TX3 network. Use correlations to specify
the relationships between events, actions and schedules.
For example, you can configure the TX3 Nano so that when access is granted, an
output on another TX3 panel is activated.
The TX3 Nano allows a maximum of 128 correlations.
Note:
TX3 Nano Configuration Manual
28
Copyright 2018
Disable Forced Entry Alarm. If you select Yes, the forced entry alarm
does not activate even if the door is opened without permission. Instead,
access is granted. This is usually used on access points where there is no
request to exit (RTE) device.
Report Door not Open. Select Yes to enable the panel to log and report
Door not open events to the Configurator when access is granted but the
door remains closed.
Auto Relock. Select Yes to lock the door as soon as the door closes.
Selecting No locks the door, but only after the expiration of the Unlock
door for timer.
Click Save Changes at the top of the window.
All inputs, outputs and schedules must be defined before applying
correlations.
Nano Settings
