To define outputs
1.
2.
3.
4.
5.
6.
2.14

Correlations

The Correlation selection lets you associate specific input events with specific
output actions.
To configure a correlation
1.
TX3 Telephone Access System Programming Manual
Version 2.7
LT-979
Copyright 2018
Press the arrow key to scroll to Outputs, and press the enter (telephone)
key. The Output selection appears.
Output Types
1 Main Door lock
2 Aux Door lock
3 GP Output 3
4 GP Output 4
Press the arrow key to scroll to the output you wish to configure and press
the telephone (enter) key. The Output Active State selection appears.
Opt Active State
< > De-energized
< x > Energized
Press the arrow key to scroll to the input you wish to configure and use the
"#" key to define the output state as energized or de-energized.
Press the telephone (enter) key. The Output selection appears.
Proceed with the rest of the input configuration or
Press info key to return to previous menu.
Press the arrow to scroll to "Correlations" in the main configuration menu
and press the enter (telephone) key. The "Correlation" selection appears.
Correlation
1 Add
2 Edit
3 Delete
Configuration
47
