Mircom TX3 Series Configuration Manual page 55

Dimensions
219 mm x 147 mm x 47 mm (8 19/32" x 5 3/4" x 1 27/32")
Weight
TX3-NANO-S4: 0.88 kg (1.95 lbs)
TX3-NANO-S4-CA, TX3-NANO-S4-CV, TX3-NANO-S4-CT, TX3-NANO-S4-CR:
0.9 kg (2 lbs)
Power over Ethernet
IEEE 802.3af/at
Auxiliary Power input
12-48 VDC / 15 W
Output
1 Form C dry contact relay with these contact ratings:
• 30 VDC/2 A
or
• 125 VAC/0.5 A
Display
colour TFT, 4.3", 480x272, high brightness (800 nits)
Camera
5 megapixel with autofocus and IR LED for night vision
Speaker
1 W nominal, 2 W maximum
Audio Codec
G.711 μ-law
Video Codecs
H.263
H.263+
H.264
MPEG-4
TX3 Nano Configuration Manual
Copyright 2018
8
Specifications
55
