Change Customer Options - Lucent Technologies DEFINITY AUDIX Installation And Upgrade

Initial System Administration
If the value in any of these fields needs to be changed, proceed to the next
section of this task to change the customer options.

Change Customer Options

NOTE:
You must use the init login to change the System-Parameters Customer-
Options screen. If this password is not available to you, contact the Remote
Support Center to have the customer options changed.
Complete the following steps only if the customer options need to be changed or
activated.
1. Log off the DEFINITY AUDIX System.
2. At the terminal login prompt, enter init. The system displays the Password
prompt.
3. Enter the password for the init login. The system displays the Enter
terminal type prompt.
4. Enter one of the valid terminal types as listed in the previous section,
Display Customer Options .
The system automatically displays the System-Parameters Customer-
Options screen as shown in the previous section. (In this case, the screen
is in the change mode.)
5. Move the cursor to the Port Emulation Type field and enter one of the
following:
6. Move the cursor to the Switch Integration Type field. Enter either display-
set for display-set integration or control-link for control-link integration
(there is a data link).
7. Move the cursor to the Maximum Number of Voice Ports field and, using
the information on the customer's order, type the number of ports that the
customer has purchased (2, 4, 6, or 8 for TN754, or 2, 4, 6, 8, 10, 12, 14,
or 16 for either TN2181 or TN746).
8. Move the cursor to the Maximum Number of Digital Networking Ports field
and, using the information on the customer's order, type the number of
ports that the customer has purchased (1 or 2; 0 is the default).
9. If the customer did not order AMIS Analog Networking, skip to Step 9.
Otherwise, move the cursor to the AMIS Analog Networking? field and
type y.
3-6
Issue 2 December 1996
tn754 if there are 8 maximum number of voice ports and display-
set emulation.
tn2181 if there are 16 maximum number of voice ports and display-
set emulation.
tn746 if two is an analog-port emulation.
