Lucent Technologies DEFINITY AUDIX Installation And Upgrade page 54

Hardware Installation
2. Connect the printer to the terminal.
a. Connect one end of the printer cable to either the serial or parallel
b. Connect the other end to the matching port (serial or parallel) on
3. Set the options on the printer. Refer to Appendix B, ''Option Settings'', for
a complete list of option settings for all supported printers.
NOTE:
When installing a serial printer on all but a 610 or 615 BCT, set the
options on the printer as described in the manual supplied with the
printer, then set the corresponding options on the terminal to match.
On the 610/615, set the terminal options, then set the printer options.
4. Proceed to Task 10: Finalize and Test the Hardware.
2-32
Issue 2 December 1996
port on the terminal (depending on which type terminal and printer
you are installing). Secure the connector with the captive screws.
NOTE:
If you are connecting a serial printer to the DTE connector on
a 715 BCT, you must connect a null modem between the
printer and the terminal.
the printer.
