Hardware Installation
1. Connect the Z3A-4 ADU to the DEFINITY AUDIX system MFB.
a. In the room where the switch and DEFINITY AUDIX system are
b. Plug the cable from the ADU into a telephone outlet.
2. In the terminal room, connect the Z3A-1 ADU to the terminal.
a. If you are installing a new terminal, unpack it according to the
b. Place the terminal on a suitable table and connect the keyboard.
c. Attach the Z3A-1 ADU (male) to a serial RS-232 port on the terminal
d. Plug one end of the D8AM crossover cord into the connector
e. Connect the 2012D ADU Power Supply to the ADU. (The power
f. Power on the terminal.
g. Set the terminal options. Refer to Appendix B, ''Option Settings'', for
2-20
Issue 2 December 1996
located, attach one end of a Group 311 cable to the RS-232
connector labeled PORT B on the MFB Y-cable (the one connected
to the fourth slot of the five DEFINITY AUDIX system slots). Attach
the other end to the Z3A-4 (female) ADU.
instructions supplied with the terminal.
(the DTE port on a 715 BCT).
NOTE:
If you connect the ADU to the DCE port on a 715 BCT, you
must also connect a null modem cable between the ADU and
the 715 BCT.
labeled Wall Jack on the ADU, and plug the other end of the D8AM
cord into a telephone outlet.
supply can be connected to either ADU.)
Attach either the 400B2 or 248B adapter to the ADU.
Plug the power supply into the adapter.
Plug the power cord on the power supply into a wall outlet.
a complete list of option settings for all supported terminals.
NOTE:
When installing a serial printer on all but a 610 or 615 BCT, set
the options on the printer as described in the manual supplied
with the printer, then set the corresponding options on the
terminal to match. On the 610/615, set the terminal options
first, then set the printer options.
