Table C-2. Identifiers for Primary Hardware — Continued
Description PEC
Opto-isolator
attribute ISO 01
Control Link 70441
direct-connect
1
cable
M-M RS-232
Group 311
cables:
1. Alternative control-link connections requiring different cables are possible. See Chapter 2,
Task 8: Install the Control-Link Cable in the DEFINITY AUDIX System Installation manual for
alternative specifications.
Table C-3. Identifiers for Primary Software
Description PEC
RTU 1253-S10
Additional
Hours of
Storage
1253-S30
1253-S50
1253-S10A
1253-S30A
C-8
Issue 2 December 1996
Comcode,
ED/H/J Drawing Qty
106 005 242 2
H600-406 G1 1
H600-406 G2 1
601 087 075 2
601 087 083 2
601 087 091 2
601 087 109 2
601 087 117 2
601 001 365 2
Comcode,
ED/H/J Drawing Qty
Notes
M-F RS-232 116A
(DC-powered switch only)
Factory installed, 1.75 ft
Upgrade, 7 ft
5 ft (Attribute: LNG05)
10 ft (Attribute: LNG50)
20 ft (Attribute: LNG25D)
30 ft (Attribute: LNG27)
40 ft (Attribute: LNG28)
50 ft (Attribute: LNG11)
Continued on next page
Notes
5 hours for 10-29 hours
5 hours for 30-49 hours
5 hours for 49+ hours
5 hours for 10-29 hours
aftermarket
5 hours for 30-49 hours
aftermarket
Continued on next page
