Hardware Installation

Worksheets Needed

Before beginning these tasks, make sure you have the following worksheets from
Planning for the DEFINITY AUDIX System , 585-300-601.
A-1, Port Slot Assignments (Before Carrier Rearrangement)
A-2, Port Slot Assignments (For Carrier Rearrangement)
A-3, Port Slot Locations for the DEFINITY AUDIX System Assembly
A-4, Control Link Cable-Connection Configuration
E-1, Terminals
The Project Manager should have provided you with these worksheets.
Task 5: Install the
System Assembly
This task is required for all installation scenarios.
!
WARNING:
To prevent damage to the DEFINITY AUDIX system assembly, make sure
that you (or the factory for new switches) have connected the DEFINITY
AUDIX system assembly adaptor cables to the port connectors on the back
of the switch (as described in Step 3) before you insert the DEFINITY
AUDIX system assembly in the switch carrier.
You can install the DEFINITY AUDIX system assembly in the switch when
the switch is powered on or off. When the assembly is inserted in the slots
of the switch carrier, it will automatically power up, run diagnostics, and
boot. To avoid a disk crash, never remove the assembly without first
completing the shutdown procedure to shut down the DEFINITY AUDIX
system (and allowing the disk to completely spin down).
For the same reason, do not power cycle the switch (for example, during
switch acceptance tests) once the DEFINITY AUDIX system assembly is
inserted unless you have first shut down the DEFINITY AUDIX system. Refer
to Chapter 1 in DEFINITY AUDIX System — Maintenance, 585-300-110, for
a description of the shutdown procedure.
