Modem Option Settings
7400B Data Module Settings
Set the two dip switches located under the top panel of the 7400B data module
as follows:
SW1-1:
— Set to ON if a telephone is not attached to the 7400B.
— Set to OFF if a telephone is attached to the 7400B.
SW1-5: 0set to ON
See 7400B Plus Data Module User's Guide , 555-020-710, for instructions on how
set options on the 7400B data module.
Issue 2 December 1996
B-19
