Hardware Installation
1. If you are installing a new terminal, unpack it according to the instructions
supplied with the terminal.
2. Place the terminal on a suitable table within 15 feet of the switch cabinet if
you have a 20-foot Group 311 cable, or within 45 feet if you have a 50-foot
Group 311 cable, and connect the keyboard.
3. Connect a Group 311 cable between the DEFINITY AUDIX system MFB
and the terminal:
a. Attach one end of a Group 311 cable (supplied with the DEFINITY
b. If you connected an opto-isolator to the PORT A and/or PORT B
c. For a 715 BCT, attach the other end of the Group 311 cable to the
d. Connect the male connector on the null modem to an RS-232 serial
4. Plug the terminal power cord into a wall outlet and power on the terminal.
5. Set the terminal options. See Appendix B, ''Option Settings'', for a
complete list of option settings for supported terminals.
NOTE:
When installing a serial printer on all but a 610 or 615 BCT, set the
options on the printer as described in the manual supplied with the
printer, then set the corresponding options on the terminal to match.
On the 610/615, set the terminal options first, then set the printer
options.
If the terminal is installed correctly (and the DEFINITY AUDIX system is in
either ADX , OAM , OS or AINIT state), the screen displays the login
prompt.
If the terminal does not display the login prompt when the DEFINITY
AUDIX system is in one of the above states, try pressing the
few times. If the login prompt still does not appear, write down the state
displayed on the LCD then see the troubleshooting procedures for
terminal connections in DEFINITY AUDIX System — Maintenance ,
585-300-110.
6. For CL integration, proceed to Task 8: Install the Control-Link Cable. For
DS integration, proceed to Task 9: Install the Printer (Optional).
2-16
Issue 2 December 1996
AUDIX system PEC) to the RS-232 connector labeled PORT A on
the MFB Y-cable (or PORT B if you are installing a second terminal).
connectors on the Y-cable (in Task 4), attach the Group 311 cable
to the opto-isolator (for a DTE connection). For a DCE connection,
attach another null modem to the opto-isolator, and attach the
Group 311 cable to the other end of the null modem.
DCE connector on the back of the terminal. Then skip to Step 4.
For a 513 or equivalent BCT, attach the other end to the female
connector on an H600-258 Group 1 null modem.
port connector on the back of the terminal.
key a
RETURN
