banks iDash 1.8 DataMonster Owner's Manual page 69

FIRMWARE UPDATES,
13.
If updating an iDash 1.8, it will
need to reset. See Figure 14-14.
Leave the microSD card
inserted for this proces
Figure 14-14
If engine is off during iDash 1.8 update,
you may need to press a button to wake
up the iDash 1.8 to finish the update.
When the iDash 1.8 wakes back up it will
begin to load new files (30-45 seconds).
See Figure 14-15.
Figure 14-15
Upon completion, a message box will let
you know the update is complete. It is
now safe to remove the microSD card.
See Figure 14-16.
CONTINUED
Figure 14-16
14.
Repeat the process (Steps 9-16)
for all iDash 1.8's or connected Banks
Modules.
69
97654 v.7
