Min & Max Values - banks iDash 1.8 DataMonster Owner's Manual

SECTION: 8
MIN & MAX VALUES
Each iDash 1.8 keeps an updated
record of key parameter minimum/
maximum values for you to view or
reset.
Some vehicles report a very
large value for an instant during
vehicle power down. This might cause
an inaccurate maximum log
To view and/or clear your
Minimum or Maximum Logs:
1.
Select "Min/Max Log" from the
main "MENU." See Figure 8-1, A.
2.
Select either "Maximum Log" or
"Minimum Log" to access logs.
See Figure 8-1, B.
3.
To reset all current min/max values
to zero, select "CLEAR ALL."
See Figure 8-1, C & D.
Maximum and minimum values
are recorded for parameters on
the Gauge Screen and on the
"Background alerts" list. Min/Max
values are recorded regardless if alerts
are enabled or disabled.
Figure 8-1
A
C
B
D
The parameter list in the
"Min/Max Log" is linked to the
"Background Alerts" and Displayed
"Alerts" lists. Adding, removing, or
changing these alerts in one menu will
change the alerts in the other.
To add/change parameters in the
"Min/Max Log" list:
1.
Select "Min/Max Log" from the
main "MENU."
2.
Select "Set Parameter."
3.
Select any "Alert #:" to change.
The "Field #" list can only
be modified in the Gauge Selection
menu.
4.
Select "Change Parameter."
If the alert is empty, you will
be skipped to Step 5.
5.
Select a "GROUP" parameter.
6.
Select an "ITEM" parameter to
change. You will be returned to the
parameter's alert options.
39
97654 v.7
