banks iDash 1.8 DataMonster Owner's Manual page 67

FIRMWARE UPDATES,
6.
Click the "Save" button to save the
firmware file to the microSD card. See
Figure 14-5.
• DO NOT change the file name of
the firmware.
• Take note of the file name so you
can select the correct firmware
later. See Figure 14-5.
DO NOT save file in a folder.
Figure 14-5
7.
(iDash 1.8 step ONLY) Extract the
firmware from the zip folder to your
microSD card.
A.
Open a file browser and
navigate to your microSD card
folder.
B.
Right click on the ".zip"
file that you just downloaded,
then click on "Extract Here".
Figure 14-6
8.
Eject and remove the microSD card
from the computer by right-clicking
on the removable drive and clicking on
"Eject". See Figure 14-6.
CONTINUED
Figure 14-7
9.
In the vehicle with the iDash 1.8
awake, insert the microSD into the
iDash 1.8; you will see a notification
stating that the microSD card is
synced. See Figure 14-8, Figure 14-9.
IF UPDATING BANKS
MODULE(S), any iDash 1.8 connected
could be used for updating the Banks
Module(s).
IF UPDATING THE iDASH 1.8, each
iDash 1.8 must be updated one by one.
Figure 14-8
Figure 14-9
SD Ready
