DIAGNOSTICS,
important parameters to monitor
during manual regeneration. (See
Figure 7-6)
During Stationary Regen, if
you have multiple iDash's, the secondary
gauges will display a message box
"Stationary Regen Running" until
the Regen is complete (Figure 7-7). The
message box will automatically clear
when the Regen is complete.
Figure 7-6
Primary
Gauge
Pressing any button on
the Primary Gauge during stationary
regeneration has begun will stop the
regeneration. (See Figure 7-6)
6.
Message will appear and let the
user know when manual regeneration
has been completed. (See Figure 7-8)
Press any to take you back to your
original gauge display.
It is recommended to
allow the engine to run for at least
10 minutes after the completion of
a stationary regen. This can be done
at idle on while driving. This reduces
the likelihood of having a stuck DEF
injector.
Figure 7-8
38
97654 v.7
CONTINUED
Figure 7-7
Secondary
Gauge

7.4 Injector Balance Rates

Check your vehicle's injector operating
tolerances. If you're experiencing a
misfire, knock, excessive smoke, or
rough running conditions with no DTCs
this diagnostic feature will help identify
if injectors are the issue.
This Diagnostics feature is
available on specific GM/Chevy Diesel
Trucks Only.
1.
Select "Diagnostics" from the main
"MENU."
2.
Select "Vehicle" for vehicle
diagnostics.
3.
Select "Injector Balance Rates"
4.
This will display individual injector
balance rates.
Balance rates are the fuel
adjustments for each individual
cylinder based off crankshaft speed.
Injectors that read outside
a +/- 4.0 in park/neutral or +/- 6.0 in
drive may be a faulty injector.
5.
Select BACK to return to the main
menu once finished. Injector balance
rate.
