Table 20 Smart Array controller POST error codes (continued)
Error
code
1729 Slot z Drive Array – Disk Performance
Optimization Scan in Progress RAID 4/5/ADG
performance may be higher after completion.
1764 Slot z Drive Array - Capacity Expansion Process
is Temporarily Disabled (followed by one of the
following):
Expansion will resume when Array Accelerator
has been reattached.
Expansion will resume when Array Accelerator
has been replaced.
Expansion will resume when Array Accelerator
RAM allocation is successful.
Expansion will resume when Array Accelerator
battery reaches full charge.
Expansion will resume when Automatic Data
Recovery has been Completed.
1768 Slot z Drive Array resuming Logical Drive Capacity
Expansion process.
1769 Slot z Drive Array - Drive(s) Disabled due to Failure
During Expansion (possibly followed by one of the
following additional details:)
Array Accelerator Removed or Failed;
Expansion Progress Data Lost.
Expansion Progress Data Could Not Be Read
From Array Accelerator.
Expansion Aborted due to Unrecoverable Drive
Errors.
Expansion Aborted due to Array Accelerator
Errors.
1770 Slot z Drive Array – Critical Drive Firmware
Problem Detected - Please upgrade firmware on
the following drive(s) using Options ROMPaq
(available from www.hp.com):
Port 1I: Box 1: Bay 1
1774 Slot z Drive Array - Obsolete Data found in Array
Accelerator. Data Found in Array Accelerator was
Older Than Data Found on Drives Obsolete Data
has been Discarded
1775 Slot z Drive Array - Storage Enclosure Cabling
Problem Detected. OUT port of this box is attached
to OUT port of previous box. Turn system and
storage box power OFF and check cables. Drives
in this box and connections beyond it will not be
available until the cables are attached correctly.
Port 1I: Box 2
1778 Slot z Drive Array resuming Automatic Data
Recovery process.
1779 Slot z Drive Array -Replacement drive(s) detected
OR previously failed drive(s) now appear to be
operational:
Port 2I: Box 1: Bay 2
1 12 Power-on Self Test (POST) error codes
Description Level
None None.
Informational or No F1 prompt if disable reason is
None "rebuild running."
None None.
Critical Press F1 to continue with logical drives
disabled. See
Press F2 to accept data loss and to
re-enable logical drives.
Warning: Pressing F2 causes
unrecoverable data loss. Be sure you
have a valid, current backup of the
affected logical drives before selecting
this option.
Informational Upgrade the firmware of the affected
drive.
Informational None.
Informational Correct the cabling problem identified
in the error message.
None None.
Critical Restore data from backup if
replacement drives have been
installed.
Corrective action
Chapter 4 (page 59).
