[-s <physical drive id>]
[-c <capacity (GB)>]
In the following example, a logical drive is configured on the Smart Array Controller with the
device filename ciss5. The RAID level is set at 1, the stripe size is set at 64 KB, and two physical
disks (identified by 2I:1:13 and 2I:1:14) are configured as a logical drive. Another physical
disk (identified by 2I:1:15) is configured as a spare for that logical drive:
# saconfig /dev/ciss5 -R 1 -S 64 -p 2I:1:13 -p 2I:1:14 -s 2I:1:15
Logical drive 0 created
Rebuild Priority is set to High
Use the saconfig /dev/cissX command to confirm the configuration:
# saconfig /dev/ciss5
******************** SmartArray RAID Controller /dev/ciss5 ********************
Auto-Fail Missing Disks at Boot
Cache Configuration Status
Cache Ratio
---------- PHYSICAL DRIVES ----------
Location Ct Enc Bay
Internal 1I 1 12
Internal 1I 1 11
Internal 1I 1 10
Internal 1I 1 9
Internal 2I 1 16
Internal 2I 1 15
Internal 2I 1 14
Internal 2I 1 13
---------- LOGICAL DRIVE 0 ----------
Device File = c5t0d0
RAID Level = 1+0
Size = 34700 MB
Stripe Size = 64 KB
Status = OK
Participating Physical Drive(s):
Ct Enc Bay
2I 1 14 0x5000c5000030b9c9
2I 1 13 0x500000e01118a7a2
Participating Spare Drive(s):
Ct Enc Bay
2I 1 15 0x5000c500002084c9
NOTE: When RAID 1 is configured on two physical disks, the saconfig /dev/cissX command
output displays the RAID level as 1+0.
saconfig <dev_file> command, as described in
"Displaying the Smart Array controller configuration"
(page 45).
Configures a physical disk as a spare. The physical disk is
identified by Connector/Enclosure/Bay or WWID. Obtain
this information from the output of the saconfig
<dev_file> command, as described in
Smart Array controller configuration" (page
Specifies the size in GB of the logical drive to be created.
If this option is omitted, the maximum capacity or the
remaining capacity is applied to the logical drive.
= enabled
= cache enabled
= 25% Read / 75% Write
WWID
0x500000e01117c732
0x500000e01115c352
0x5000c5000032b839
0x5000c5000030b0c5
0x500000e011213482
0x5000c500002084c9
0x5000c5000030b9c9
0x500000e01118a7a2
WWID
WWID
Size Status
36.4 GB UNASSIGNED
36.4 GB UNASSIGNED
36.4 GB UNASSIGNED
36.4 GB UNASSIGNED
36.4 GB UNASSIGNED
73.4 GB SPARE
36.4 GB OK
36.4 GB OK
The saconfig configuration CLI
"Displaying the
45).
