E Cable kits

This appendix provides details on the internal and external cable kits available for HP Smart Array
SAS controllers.
Table 21 Internal SAS cable kits
Multilane A cable
Host fan cable
Target fan cable
Multilane B cable
Multilane 76-cm (30-in) cable
Multilane 48-cm (19-in) cable
Table 22 External SAS cable kits
Type of Cable
External SAS
External SAS
External SAS
External SAS
NOTE: All HP cables are keyed so they cannot be installed incorrectly.
You can order additional cables from an authorized HP reseller or authorized HP service provider.
If the cable that you need is not listed here, or if you need additional ordering information, see
the HP website at http://www.hp.com.
Description
Length
1.0 m (3.3 ft)
2.0 m (6.6 ft)
4.0 m (13 ft)
6.0 m (20 ft)
Part Number
389647-B21
389650-B21
389653-B21
389659-B21
389662-B21
391330-B21
Part Number
389665-B21
389668-B21
389671-B21
389674-B21
1 17
