HP Smart Array -UX 11i v2 Support Manual page 120

Table 26 Smart Array P71 1m controller specifications (continued)
Maximum number of physical drives (using
all four ports)
Maximum number of logical drives
Memory bus speed
Number of SAS ports
SAS port link rate
Disk drive and enclosure protocol support
Cache module
Table 27 Smart Array P800 controller specifications
Card type
Dimensions (excluding bracket)
Maximum power required
Time required to recharge battery
Duration of battery backup
Battery life expectancy
Spare battery part number
Operating temperature range
Storage/shipping temperature range
Operating relative humidity (noncondensing)
RAID levels supported
Maximum number of physical drives (using
all four ports)
Maximum number of logical drives
Capacity
Type of edge connector
PCI Express support
PCI Express transfer rate
Number of SAS ports
SAS transfer rate
Drive types supported
Cache size
120 Controller specifications
108 external
512 external
DDR2-800 (6.4 GiB/s maximum bandwidth)
Four (4) 2x connectors external
6Gb/s per physical link
SAS protocol: 6 Gb/s, 3 Gb/s, or 1.5 Gb/s
SATA protocol: 3 Gb/s or 1.5 Gb/s
72-bit wide, 1-GB FBWC (1 12 MB is used by the onboard processor)
Full-Size PCIe
31.1 cm × 1 1.1 cm × 1.2 cm (12.3 in × 4.4 in × 0.5 in)
Approximately 25W
15 minutes to 2 hours, depending on initial battery charge level
More than 2 days, with fully-charged batteries that are less than 3 years
old
More than three years
398648-001
10º to 55º C (50º to 131º F)
-30º to 60º C (-22º to 140º F)
10% to 90% (Storage/shipping 5% to 90%)
0, 1, 1+0, 5, 6 (ADG)
108 (8 can be connected internally, and the remaining100 can be
connected externally by using expanders)
32
Up to 5.8 TB of external storage per PCI slot with 4 HP StorageWorks
MSA50 enclosures and 40 x 146 GB SFF SAS hard drives.
Up to 28.8 TB of external storage per PCI slot with 8 HP StorageWorks
MSA60 enclosures and 96 x 300 GB 3.5" SAS hard drives
Up to 14.6 TB of external storage per PCI slot with 4 HP StorageWorks
MSA70 enclosures and 100 x 146 GB SFF SAS hard drives
PCIe x8
2.5 Gb/s PCI Express
Up to 2 GB/s in each direction
Two internal, two external; each port has four 1x links
Up to 1.2 GB/s per port in each direction
3.0 Gb/s SAS
512 MB (approximately 48 MB is used by the onboard processor)
