Table 5 Interpreting Smart Array P700m runtime LEDs
LED ID Color
1 Amber
2 Amber
3 Amber
4 Amber
5 Green
6 Green
7 Green
8 Green
9 Green
10 Green
Table 6 Determining the Smart Array P700m controller CPU activity level
LED 9 (Gas Pedal) Status
Off
Flashing
On Steady
On steady
NOTE: During server power on, each runtime LED illuminates randomly until POST completes.
12 Controller overview
Name LED name and interpretation
CR10 Thermal Alert LED. This LED is not used.
CR9 System Error LED. The controller ASIC has locked up and cannot process
any commands.
CR1 Diagnostics Error LED. One of the server diagnostics utilities has detected
a controller error.
CR2 Disk Failure LED. A physical disk connected to the controller has failed. See
the Fault LED on each disk to determine the failed disk.
CR3 Activity LED for SAS port 2.
CR4 Activity LED for SAS port 1.
CR5 Command Outstanding LED. Indicates that the controller is working on a
command from the host driver.
CR6 Controller Heartbeat LED. This LED flashes every two seconds to indicate
controller health.
CR7 Gas Pedal LED. This LED, with item 10 (CR8), indicates the amount of
controller CPU activity. See
CR8 Idle Task LED. This LED, with item 9 (CR7), indicates the amount of controller
CPU activity. See
LED 10 (Idle Task) Status
Flashing
Off
Off
On Steady
Table 6.
Table 6.
Controller CPU activity level
0 to 25%
25 to 50%
50% to 75%
75% to 100%
