5
Overview of equipment and control elements
5.1 Overview of equipment
Overview of equipment and control elements
2
1
Fig. 2: Overview of equipment DFYa, complete
1
Liquid end
2
HMI
3
Motor
4
Control unit (in the pump foot)
5
Gear
1
7
6
Fig. 3: Liquid end of DFYa
1
Front cover (transparent)
2
Star screw
3
Dosing head
4
Pressure connector (depending on the identity code)
5
Suction connector (depending on the identity code)
6
Rotor
7
Roller
not shown Hose rupture sensor
3
4
5
2
3
B1171
4
5
B1173
17
