Identity code "1"
1
4
Fig. 18: Assignment on the pump
9.3.4.3 Output for other relays (identity code "3")
P_SI_0044
Fig. 19: Assignment on the cable
Identity code "3"
4
1
3
2
Fig. 20: Assignment on the pump
9.3.4.4 "Current output plus relay" output (identity code "8")
To pin VDE cable
1 white
2 Green
2
4 brown
P_G_0072_SW
A fault indicating and a pacing relay can be ordered as options - refer to
ordering information in the appendix. The pacing output is electrically iso‐
lated by means of an optocoupler with a semiconductor switch. The
second switch is a relay (also electrically isolated).
The behaviour is factory-programmed. If another switching function is
wished, the pump can be reprogrammed in the
The fault indicating/pacing relay can be retrofitted and is operational once
attached to the relay board - refer to the "Retrofitting relays" supplemen‐
tary instructions.
Electrical interface
for semiconductor fault indicating / pacing relay:
Data
Max. residual voltage at I
Maximum current
Maximum voltage
Pacing pulse duration, approx.
To pin VDE cable
1 yellow
4 Green
3 white
2 brown
P_G_0073_SW
A relay combined with a current output can be ordered as an option. The
relay either switches as a fault indicating relay in the event of a fault on the
pump and with "Liquid level low 1st stage" warning message and "Liquid
level low 2nd stage" fault messages or is used as a pacing relay.
The behaviour is factory-programmed. If another switching function is
wished, the pump can be reprogrammed in the
Installation, electrical
Contact
N/O (normally open)
N/C (normally closed)
C (common)
'Relay' menu.
= 1 µA
off max
Contact
N/O (normally open)
C (common)
N/O (normally open)
C (common)
'Relay' menu.
CSA cable
white
red
black
Value Unit
0.4 V
100 mA
24 VDC
100 ms
Relay
Fault indi‐
cating relay
Fault indi‐
cating relay
Pacing relay
Pacing relay
