Overview of equipment and control elements

4 Overview of equipment and control elements
12
4
5
Fig. 3: Overview of equipment and control elements S3Ba
1 Drive motor
2 Drive unit
3 Stroke length adjustment knob
4 Liquid end with relief valve
5 Diaphragm rupture sensor
1
2
Fig. 4: Sigma control elements
1 Relief valve
2 Diaphragm rupture sensor (visual)
1
2
3
P_SI_0070_SW
P_SI_0088_SW
