Assemble Sides

Place all the parts for the sides on a level surface.
Make sure the pieces are in the correct positions before assembling.
!
Carefully follow the order of assembly to ensure an easy installation.
Wear proper safety gear including work shoes, gloves and goggles.
!
You are assembling both sides in the following steps. Both sides are identical until Step 4.8
4.1A Line up the four pro les L03V so the holes are at the same position. Slide short side of connectors
S01 into channel of pro le until the last hole in S01 lines up with third hole from the bottom on
pro le L03V.
4.1B
S01
L03A
L03V
28"
(715 mm)
6 1/2"
(165 mm)
Lay out pro les L04D so the holes are at the same position. Slide short side of connector S01 into
4.2A
channel of pro le, lining the last hole in S01 with the hole on pro le L04D.
S01
L04D
www.stcny.com
IMPORTANT: The holes are not at the midpoint of the pro le.
Arrange pro le so the 28" portion will be the bottom when standing.
Slide another connector S01 so it lines
up with the middle hole on pro le L03V.
4.1C
S01
L03V
4.2B Secure with S02 screw. Repeat to make four sets.
S02
Secure all pieces with S02
screws. Repeat to make four sets.
Pro le
#L03V
NOTE: ALL VIEWS ARE FROM INSIDE.
Pro le
#L04D
