Page 1
Clear View 8’ x 12’ Greenhouse Assembly Instructions Systems Trading Corporation 450 7th Avenue Suite 2809, New York, NY 10123 Customer Service: (877) 407-9100 ext 1 Email: customerservice@stcaustin.com...
Page 3
Introduction Thank you for purchasing the 8x12 Clear View Greenhouse. This greenhouse combines clear window shaped panels for the sides with the functionality of twin panel polycarbonate panels to help maintain consistent temperature. This model features two roof vents and a circular air vent to ensure proper ventilation.
Page 4
Safety Advice Table of Contents The greenhouse must be positioned and xed on a at Introduction ........level surface. Safety Advice ......... Dispose of all plastic bags safely. Keep them out of the General Order of Assembly ..reach of small children. List of Parts ........
Page 5
Place all the parts for each step in staging areas, checking that you have all parts as you go. If any parts are missing or damaged, contact STC customer service before beginning assembly: Customer Service: (877) 407-9100 ext. 1 or email: customerservice@stcaustin.com...
Page 8
Assemble Back Place all the parts for the back face on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. The back is assembled with the outside face to the ground.
Page 9
Attach pro les G02B and G03C to pro le G17C by sliding the long sides of 1.3A connector S01 into channels lining up last hole in S01 with holes in pro le G17C. Attach pro les G03D and G02A to pro le G17D by sliding the long side of connector S01 into pro le channels lining up last hole of S01 with holes in G17D.
Page 10
1.4A Slide connector G16A inside pro les G03L and G03K. The two end holes on each side of connector G16A line up with the two holes on each pro le. 1.4B Secure with four S02 screws. G03L G03L G03K Pro le Connector G16A #G03K...
Page 11
1.6A Slide connector G16 inside pro les G01I and G01J. 1.6B Line up the outside holes on G16A with second hole on pro les G01I and G01J. Secure with two S02 screws. G01I G01I G16A G01J G01J NOTE: ALL VIEWS ARE FROM INSIDE Pro le Connector #G01I...
Page 12
Remove protective plastic from both sides of panels GY2 . The clear panels are designed with window shapes that curve outward. Place the outward curved side G03L facing down. The rst row of ribbed edges t securely into V-channels of pro les G02A, G02B, G03C, G03D, G17C G02B and G17D.
Page 13
1.9A Slide hex bolt S13 into channels of four G05H pro les as shown. 1.9B Screw hex nut S14 onto bolt. Do not completely tighten. G05H G05H G05H G05H Pro le Bolt/Nut NOTE: Insert two sets of nuts and bolts into two G05H pro les. #S13 #L05H The other two G05H pro les have one set of nuts and bolts.
Page 14
Remove protective plastic from both sides of panels GY7, GY8, GY16 and 1.10C GY17. The clear panels are designed with window shapes that curve outward. Place the outward curved side facing down. Slide panels into V-channels on pro les G02A, G02B, G03C, G03D and G03L. Fit inside V-channels on pro les G05H.
Page 15
Slide connectors S09 and S10 half way into pro les G02A and G02B. 1.11B Continue sliding together making sure rst row of ribbed edges on panels GY7, GY8, GY16 and GY17 t securely into V-channels of pro les G02I GY17 and G02J.
