Slide shelf pro le L14C at a slight angle so one end slides half way into connector S39 and the
7.3A
other side with connector S37 rests on top of pro le L04A. Continue to slide until pro le clicks
into connector S39.
L14C
S39
Repeat step 7.3A, sliding shelf pro le L14D into
7.3B
S39 connector. Make sure
connector S37 rests on top
of pro le L04A.
!
7.3C
Secure S37 connectors to L04A pro les
with four S02 screws.
L04A
L14D
L14B
VIEWS FROM INSIDE.
www.stcny.com
Connector S39 CLICKS into place.
S37
L14C
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
L07D
L04A
L14A
S39
L14D
S39
Connector S39 CLICKS into place.
39 of 57
L04A
L14A
L14C
Screw
QTY
#S02
4
