4.10A
Place pro les L03B and L03V onto pro les L07D and L01D. Line up holes as shown.
Secure with six S02 screws.
4.10B
L07D
L07D
L07D
L03B
L03V
L07D
L03V
L03V
L03B
L03B
S02
L01D
L01D
L01D
Pro le
Pro le
Screw
QTY
QTY
QTY
#L01D
1
#L07D
1
#S02
6
4.11
Slide connectors S19 and S03 into pro le L03T until they click securely into place. Repeat to
make two sets.
S19
S19
NOTE: ALL VIEWS ARE FROM INSIDE.
L03T
L03T
L03T
S03
Pro le
Connector
Connector
QTY
QTY
QTY
S03
#S03
2
#S19
2
#L03T
2
www.stcny.com
31 of 57
