STC Easy2Build Easy-Grow Assembly Instructions Manual page 45

From inside of greenhouse, secure S20 connectors
8.7A
to gable pro les L03M, L03N, L03Q, L03R, L03S and
L03U with two S02 screws.
L03S
S20
S02
L03R
S20
S02
VIEWS FROM INSIDE.
8.8A From inside of greenhouse, line up bracing bar
S23 with holes in gable pro les L03U, L03R and
L03S. Secure one S02 screw partially into each
end. Then go back and tighten both screws.
L03U L03U
S23
S02 S02
VIEWS FROM INSIDE.
From inside of greenhouse, place S23 bracing bars S23 onto the center three side and gable
8.8B
pro les. Line up holes in pro les L03V and L03U, L03T and L03Q, L03T and L03N, L03V and L03R
and L03V and L03S with holes in S23 bracing bar.
L03U
S23
L03V
L03N
S23
L03T
L03S
S23
L03V
VIEWS FROM INSIDE.
www.stcny.com
L03S L03R
S23
S02 S02
8.8C Secure one S02 screw partially into each
end. Tighten both screws.
43 of 57
8.7B Secure each S22 connector to pro les
L02G and L02H with one S02 screw.
L02H
S22
VIEWS FROM INSIDE.
S02
S02
L03V
S02
S02
L03V
Screw
QTY
#S02 16
S02
Screw
QTY
#S02 15
L03U
L03Q
S02
L03R
S02
L03T
Brace
QTY
#S23 8
