1.4A
Slide connector L16 inside pro les L03L and L03K. The two end holes on each
side of connector L16 line up with the two holes on each pro le.
1.4B
L03L
L16
1.5A
L03K
L02B
NOTE: ALL VIEWS ARE FROM INSIDE
www.stcny.com
Secure with four S02 screws.
L03L
S02
S02
L03K
Slide connectors S08 into channels
of pro les L03C, L03D and L03K.
L03L
L03C
L03K
S08
S08
Pro le
#L03K
#L03L
1.5B
Secure each connector with
two S02 screws.
L03D
S08
8 of 57
Connector
QTY
QTY
1
#L16
1
#S02
S02
S08
L02A
Connector
QTY
#S02
#S08
1
4
6
3
