STC Easy2Build Easy-Grow Assembly Instructions Manual page 30

4.3
Slide connector S39 into pro le L04D until it snaps into place.
Repeat to make four sets.
S39
L04D
4.4
Slide connector S03 into
pro le L04B until it clicks into place.
S03
4.5A Attach pro les L04B and L04C to pro le L03V by sliding the long sides of connectors S01 into the
channels. The last hole of connector S01 lines up with the holes in the pro les.
4.5B Secure with two S02 screws. Repeat to make four sets.
L03V
S01
L04B
S01
L04C
NOTE: ALL VIEWS ARE FROM INSIDE.
www.stcny.com
S39
Connector S39 CLICKS into place.
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
IMPORTANT: Connector S03 rests on top of connector
S01. S02 screw secures S03 to pro le L04B.
S02
S03
Connector S03 CLICKS into place.
L04B
Pro le
#L04B
L04C
S02
Pro le
#L04C
28 of 57
Connector
#S39
Connector
QTY
4 #S03
L04B
S03
L03V
Screw
QTY
4 #S02
QTY
4
QTY
4
QTY
8
