Carefully line up connector S04 with pro le L02B and connector S05 with pro le
1.7A
L02A. Slide pro les L01I and L01J half way into place. Continue sliding
until connectors S04 and S05 click securely into pro les.
L03L
L02B
L03C
L03K
S04
L01I
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
1.8A
Slide hex bolt S13 into channels of pro les L05A and L05H as shown.
L05A
L05H
www.stcny.com
NOTE: ALL VIEWS ARE FROM INSIDE.
1.7B
L03D
L02A
L01J
S05
1.8B
Screw hex nut S14 onto bolt. Do not completely tighten.
S14
S13
10 of 57
Line up holes on connectors S08 with holes in
pro les L01I and L01J. Secure each connector
with two S02 screws.
L01I
Connectors S04 and S05 CLICK into place.
L05A
Pro le
QTY
#L05A
2
#L05H
2
S08
S02
Screw
QTY
#S02
6
L05H
Nut / Bolt
QTY
#S13
6
#S14
6
