STC Easy2Build Easy-Grow Assembly Instructions Manual page 20

Place door pro les L13D, L13F, L13G and L13H next to connectors S28 around
2.8B
Y26 panels as shown. Slide connectors into pro les. Make sure panels and
pro le L05F t into V-channels of each pro le.
L13G
S28
L13H
2.8C
Secure connectors with eight S02 screws.
L13G
L13H
2.8D Slide hex nuts and bolts into
U-cutout in side of pro les L13F
and L13H. Tighten securely to hold in place.
Place S40 locks on pro les L13D and
2.9A
L13G as shown. Center the levers so
the screw holes are visible.
S40
L13G
L13H
S40
S40
L13G
IMPORTANT: Install door locks so levers face the panels.
Pro le
QTY
1
#L13F
www.stcny.com
S28
L13F
L05F
NOTE: ALL VIEWS ARE FROM INSIDE.
L13F
L13D
Pro le Lock
QTY
1
#L13D
1
#L13G
#L13H 1
S28
L13F
2.9B Secure each S40 lock with two S40A screws.
S40A
L13G
S40
L13D
NOTE: Door locks are shown in the UNLOCKED
positition. When door is installed in Step 15 and door
is closed, move lever to the left side to lock door.
Screw
QTY
#S40 2
4
#S40A
18 of 57
S28
S28
L13D
S02
L13D
S40A
L13D
Move lever to the right
2.9C
side to place lock in the
unlocked position.
L13G L13D
Connector
QTY
#S28
8
#S02
QTY
4
