STC Clear View Assembly Instructions Manual

8' x 12' greenhouse
Hide thumbs Also See for Clear View:
Table of Contents

Advertisement

Quick Links

Download this manual
7
10
Clear View
TM
8' x 12' Greenhouse
Assembly Instructions
Systems Trading Corporation
450 7th Avenue Suite 2809, New York, NY 10123
Customer Service: (877) 407-9100 ext 1 Email: customerservice@stcaustin.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Clear View and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STC Clear View

Summary of Contents for STC Clear View

  • Page 1 Clear View 8’ x 12’ Greenhouse Assembly Instructions Systems Trading Corporation 450 7th Avenue Suite 2809, New York, NY 10123 Customer Service: (877) 407-9100 ext 1 Email: customerservice@stcaustin.com...

  • Page 3: Introduction

    Introduction Thank you for purchasing your Clear View 8x12 Greenhouse. This model features two roof vents and a circular air vent to ensure proper ventilation. We have also included an automatic vent opener to help greenhouse will provide years of enjoyment.

  • Page 4: Table Of Contents

    Safety Advice Table of Contents Introduction ........level surface. Safety Advice ......... Dispose of all plastic bags safely. Keep them out of the General Order of Assembly ..reach of small children. List of Parts ........Keep children and pets away from the assembly area until Assemble Back ......

  • Page 5: List Of Parts

    Place all the parts for each step in staging areas, checking that you have all parts as you go. If any parts are missing or damaged, contact STC customer service before beginning assembly: Customer Service: (877) 407-9100 ext. 1 or email: customerservice@stcaustin.com...
  • Page 6 Clear Panel Clear Panel Step 3 Step 12 GY12 Step 1 Step 12 GY13 Step 3 GY16 Step 1 Step 3 GY17 Step 1 Step 1 GY18 Step 3 Step 1 GY19 Step 3 Step 1 Step 1 GY20 Door Hinge Parts Step 1 GY21 #P30...
  • Page 7 Connector Connector Steps 1,3,4 Steps 3,4 Steps 2,3,4 Step 4 S08C Step 3 Steps 1,3 Step 1,3 Steps 1,3 S17L Step 3 Steps 1,3 S17R Step 3 Steps 1,3 Step 4 Step 9 Step 1 Steps 5,15 Step 3 G16A Steps 1 Step 4 Connector...

  • Page 8: Assemble Back

    Assemble Back Place all the parts for the back face on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. The back is assembled with the outside face to the ground.
  • Page 9 Assemble Back Place all the parts for the back face on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. The back is assembled with the outside face to the ground.
  • Page 10 1.3A channels lining up last hole of S01 with holes in G17D. G03C G02B G03D G17C G02A G17D 1.3B Secure with four S02 screws. G03C G03D G02B G02A G17C G17D NOTE: ALL VIEWS ARE FROM INSIDE. Screw #G17C #S02 #G17D 7 of 56 www.stcny.com...
  • Page 11 1.4A 1.4B Secure with four S02 screws. G03L G03L G03K Connector G16A #G03K #G16A #S02 #G03L 1.5A Slide connectors S08 into channels 1.5B Secure each connector with two S02 screws. G03K G03L G02B G03C G03D G02A G03K Connector #S02 NOTE: ALL VIEWS ARE FROM INSIDE #S08 8 of 56 www.stcny.com...
  • Page 12 1.6A 1.6B Line up the outside holes on G16A with second S02 screws. G01I G01I G16A G01J G01J NOTE: ALL VIEWS ARE FROM INSIDE Connector #G01I #G16A #S02 #G01J 1.6C click into place. Connectors P04 and P05 CLICK into place. G01I G01J G01J...
  • Page 13 Remove protective plastic from both sides of panels GY2 . The clear panels are designed with window shapes that curve outward. Place the outward curved side G03L G02B, G03C, G03D, G17C G02B and G17D. G03C G17D G03K G03D G02A Remove protective plastic from EACH side of clear Clear Panel panels before installing.
  • Page 14 1.9A 1.9B Screw hex nut S14 onto bolt. Do not completely tighten. G05H G05H G05H G05H Bolt/Nut #S13 #S14 Remove protective plastic from both sides of panels GY20 and GY21. The clear panels are 1.10A designed with window shapes that curve outward. Place the outward curved side facing down. Remove protective plastic from EACH side of clear panels before installing.
  • Page 15 Remove protective plastic from both sides of panels GY7, GY8, GY16 and 1.10C GY17. The clear panels are designed with window shapes that curve outward. Place the outward curved side facing down. the V-channels. Remove protective plastic from EACH side of clear panels before installing.
  • Page 16 1.11B P09 and P10 row of ribbed edges on panels GY7, and G02J. Connectors click GY17 GY16 G02B Connectors P09 and P10 CLICK into place. G02A 1.12A and G03C, G02J and G03L and G02J and G03D matching up all holes. 1.12B Screw S02 screws partially into bottom two holes.
  • Page 17 Insert long side of cable connector S06 at an angle 1.13A UP. Slide connector to other side of channel. Use hex key to securely tighten and hold in place. G02B G17C G17D G02A G01I G01J 1.13B Attach one side of short cable S16 to hook on S06 second S06 cable connector and with hook facing center, insert into square and cable is tight.

  • Page 18: Prepare Doors

    Prepare Doors Place all the parts for both doors on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. installing.
  • Page 19 Place brace G15D onto DOOR 1G lining up the holes on each end with the holes Secure brace with two S52 screws and S14 hex nut. G13B G13E G13B DOOR 1G G15D G13C G13C G13E G13E IMPORTANT: The hole for hex bolt is not at the midpoint of brace. Turn brace until all holes line up.
  • Page 20 2.4A Remove protective plastic from both sides of panels on DOOR 2G. Place side to face the sun facing down. DOOR 2G Remove protective plastic from EACH side of clear panels before installing. Dispose of plastic properly. Install with outward curved side FACING DOWN. 2.4B Remove S52 screws and S14 nut as shown.
  • Page 21 2.5A Door 2G shown. Center the levers so the screw holes are visible. G13G G13G G13D DOOR 2G IMPORTANT: Install door locks so levers face the panels. G13D 2.5B Secure each S40 lock with two S40A screws. S40A S40A G13D G13G Move lever to the right side to place lock in the unlocked position.

  • Page 22: Assemble Front

    Assemble Front Place all the parts for the front face on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. The front is assembled with the outside face to the ground.
  • Page 23 3.2A connectors do not snap into place. G06J G06K G06J S17L G06A S17R Place connectors S17L and S17R 3.2B on corners matching up bottom G06K G06A, G06J and G06K as shown. G06A S17L Secure each connector 3.2C S17R with S52 screws. S17R S17L G06K...
  • Page 24 3.4A Slide connector S08 into 3.4C G03W G03W G03W G06J 3.4B Secure with G06J two S02 screws. G06K G06A Secure with two S02 screws. 3.4D Connector NOTE: ALL VIEWS ARE FROM INSIDE. #S02 #G03W #S08 Connectors P09, P10 and P18 CLICK into place. G02K G02K G02L...
  • Page 25 Remove protective plastic from both sides of panels GY5, GY6, GY18 and GY19. The clear panels are designed with GY19 window shapes that curve outward. GY18 Place the outward curved side facing G03W G06J G02B G06K G06A G17B G02A G17A Remove protective plastic from EACH side of clear Clear Panel Clear Panel...
  • Page 26 Loosen the four screws in connectors S17L and S17R enough to adjust door 3.7B G02L with two S02 screws and tighten four screws G02K S17R G06J S17L G02L G02K G06A G06K S17R S17L 3.7C 3.7E Screw S02 screws into top and G03W, lining up all holes.
  • Page 27 3.8C 3.8B Secure with two S02 screws. Line up connector S08C with holes on S08C G01O G01O 3.9A until they securely click into place. G01M G01N G01O G01O G01O G01M G01N IMPORTANT: Connectors P01 and P03 look very similar. P01 has built in nuts used to support door hinges installed in Step 14.
  • Page 28 3.10 As you slide bottom pro les G01M, G01O and G01N half way into place, carefully line up P01 connectors with channels on pro les G06K and G06A and P04 connectors with pro les G02B and G02A. Continue sliding, making sure panels GY1 and GY9 t into V-channels.
  • Page 29 Insert long side of cable connector S06 at an 3.11A FACING UP. Slide connector to other side of channel. Use hex key to securely tighten and hold in place. G02A G06A G06K G02B G01O NOTE: ALL VIEWS ARE FROM INSIDE. G01M 3.11B Use hex key to securely tighten and hold in place.

  • Page 30: Assemble Sides

    Assemble Sides Place all the parts for the sides on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. You are assembling both sides in the following steps.
  • Page 31 Repeat to make four sets. G04D Connector #P39 Connector P39 CLICKS into place. Slide connector P03 into Connector P03 CLICKS into place. G04B Connector #G04B #P03 4.5A into the Secure with two S02 screws. Repeat to make four sets. 4.5B IMPORTANT: Connector P03 rests on top of connector G03V G04B...
  • Page 32 4.6A 4.6B Secure with S02 screw. Repeat to connector S01 into channel of G04C. make four sets. Connector P39 CLICKS into place. G03V G04B G04C Screw #S02 G04D 4.7A Slide long side of connectors S20 4.7B Secure with three S02 screws. Repeat to make four sets.
  • Page 33 4.8A lining up holes as shown. 4.8B Secure with three S02 screws. Repeat to make four sets. G03B G03B Connector Connector #S02 #S02 #G03B #S20 #S08 4.9A 4.9B Secure with six S02 screws. Repeat to make two sets. G07C G07C G07C G03B G03V...
  • Page 34 4.10A Secure with six S02 screws. Repeat to make two sets. 4.10B G07D G07D G07D G03B G03V G07D G03V G03B G03V G03B G01D G01D G01D Screw #G01D #G07D 2 #S02 4.11 make two sets. NOTE: ALL VIEWS ARE FROM INSIDE. Connectors P01 and P19 CLICK into place.
  • Page 35 4.12 Carefully slide sections together as shown. We recommend using two people for this step. Repeat to make two sets. G07D G07C G07C G03B G03V G07D G03T G03V G14J G03B G14J G01D G01D Connectors P01, P03, P19 and P39 CLICK into place. G01D G01D NOTE: ALL VIEWS ARE FROM INSIDE.

  • Page 36: Prepare Shelves

    Prepare Shelves Place all the parts for the shelves on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. 5.1A connector with the hole in the channel.

  • Page 37: Connect Sides To Back

    Connect Sides to Back With the outside facing a wall, carefully stand back up and lean against the wall. Stand each side up and place next to the back. Both sides are identical G07A and G07B match the diagrams before connecting. 6.1A Set up one side facing inside with G07C next to the back.
  • Page 38 6.2A G07D connector P03 until it clicks into place. Slide clicks into place. G14D G07C G14D G14C G14C Connectors P03 and P39 CLICK into place. 6.2B G17D. Push side in until connectors click into place. Connector P10 CLICKS into place. G07D G17D G07D...

  • Page 39: Connect Sides To Front

    Connect Sides to Front Keep the structure as is, with the back against the wall until you right side until it clicks into place. Connectors P03 CLICK into place. G14D G07D G14D G07C G14C Connectors P03 CLICK into place. G14C VIEWS FROM INSIDE.
  • Page 40 7.2A G07D G14D G07C G01D G01D 7.2B click into place. Connectors P09 and P10 CLICK into place. G07C G17B G07D G14D G07C G14C G01D G01D G01D Connectors P04 and P05 CLICK into place. 37 of 56 www.stcny.com...
  • Page 41 7.3A into connector P39. Connector P39 CLICKS into place. G14C G07D G14D G17A G14C 7.3B P39 connector. Make sure G14D connector S37 rests on top Connector P39 CLICKS into place. 7.3C with four S02 screws. G17A G14D G14C G17B G14D G14C Screw VIEWS FROM INSIDE.

  • Page 42: Prepare Roof Vents

    Prepare Roof Vents Place all the parts for both roof vents and handles on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. on both sides of panels before installing.

  • Page 43: Connect Gables And Roof Vents

    Connect Gables and Roof Vents Place all the parts for the gables on a level surface. Make sure the pieces are in the correct positions before assembling. Please carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including shoes, gloves and goggles. 9.1A 9.1B Secure each set with...
  • Page 44 From the inside of the greenhouse, use two people to carefully lower center gable onto frame. Connectors P19 CLICK into place. G03N G03N G03Q G03Q IMPORTANT: U-shaped cutouts on G03N G03Q shaped. Stickers with arrows are placed on that From the inside of the greenhouse, use two people to carefully lower front and back gables onto IMPORTANT: U-shaped cutouts on G03S G03S...
  • Page 45 9.5A connector P21 at a slight angle. G02N IMPORTANT: Have the roof vents nearby. You will install the roof vent BEFORE connecting both sides of G02N. It is best to use two people for this step. rectangular holes in channels face the LEFT when looking at the front of the greenhouse from the outside. 9.5B Note: Roof vents are prepared in step 8.
  • Page 46 From inside of greenhouse secure S20 connectors Secure each S22 connector to 9.7A 9.7B G03U with two S02 screws. G02H G03S G03R VIEWS FROM INSIDE. Screw VIEWS FROM INSIDE. 9.8A From inside of greenhouse, line up bracing bar G03S. Secure one S02 screw partially into each end.
  • Page 47 9.9B 9.9A Screw two S14 hex nuts onto bolts on ends of each Slide two S13 hex bolts into channel of G05D G05D G05G G05G Bolt / Nut #S13 #G05D #G05G #S14 9.10 Unpack contents of Auto Vent Opener. Follow instruction manual included with Auto Vent Opener to assemble.
  • Page 48 Use the hairpin clips connected to G05D to secure the handle and prevent the vent from 9.11C opening and closing in high winds. G05D 9.12A G03S VIEW FROM OUTSIDE. G05G G03S G03N G05G 9.12B Line up G05G channel with U-shaped Slide hex nut and bolts into U-shaped notches and tighten securely.

  • Page 49: Brace Sides

    Brace Sides Place all the parts for bracing the sides on a level surface. Make sure the pieces are in the correct positions before assembling. Please carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including shoes, gloves and goggles. From the inside of the greenhouse, insert long side of cable connector 10.1A other side of channel.
  • Page 50 10.3A G07D with hook facing the back. Slide connector to other side of channel. Use hex key to securely tighten and hold in place. G07D G02A G02A G07D G14D Attach one side of long cable S07 to hook and lace 10.3B second S06 cable connector.

  • Page 51: Install Circular Vent

    Install Circular Vent Place all the parts for circular vent on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. 11.1A Open box containing the parts for circular vent.

  • Page 52: Install Side And Roof Panels

    Install Side and Roof Panels Place all side and roof panels on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. 12.1 Remove protective plastic from both sides of panels GY12 and GY13.

  • Page 53: Install Trim Plates

    Install Trim Plates Place the trim plates on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles. 13.1 Remove the six hex nuts from the hex bolts attached to each G09C and G09D trim plate BEFORE installing.
  • Page 54 13.4A In the front of the greenhouse, slide plastic trim plates J02L, J02R, and J03 into connectors P09, P10 and P18 until they snap into place. On top of the greenhouse, snap trim plate J06 onto connector P21 and slide towards the back until it snaps into place.

  • Page 55: Hang Doors

    Hang Doors The doors have been assembled in Step 2. When hung, the bracing bars and door locks are on the inside of the doors in the greenhouse. We recommend using two people to hang the doors. 14.1A Install hinges to door frame. Line up door hinge P30 with holes G06A G06A G06K...
  • Page 56 14.2A Place S49 pin in bottom door hinges G06K on both sides of door frame. G06K G06A 14.2B From the outside of the greenhouse, carefully line up hinge on bottom of DOOR 1G with S49 pin on right side of door frame. Lower door frame onto pin until hinges meet.
  • Page 57 14.3A From the outside of the greenhouse, carefully line up hinge on bottom of DOOR 2G with S49 pin on left side of door frame. Lower door frame onto pin until hinges meet. Push top door back towards door frame so top hinges line up. 14.3B Line up top door hinge with top door frame hinge.

  • Page 58: Secure To Ground

    Secure to Ground Make sure the foundation is FLAT and LEVEL. Make sure the greenhouse is square. The two diagonal measurements inside the greenhouse should be identical. From the inside of the greenhouse, insert the S34 anchor clips sides. Place the S35 pegs through the holes and into the ground to establish proper the concrete is partially dry, use a hammer to drive the pegs all the way into the concrete and let dry completely for twenty four hours.

  • Page 59: Install Trays And Bin Holder

    Install Trays and Bin Holder Place all the parts for the trays and bin holder on a level surface. Make sure the pieces are in the correct positions before assembling. Carefully follow the order of assembly to ensure an easy installation. Wear proper safety gear including work shoes, gloves and goggles.
  • Page 60 Notes:...
  • Page 61 Clear View 8’ x 12’ Greenhouse Assembly Instructions Please keep this manual in a safe place for reference, service and warranty. If you need any help or have missing or damaged parts, please contact us. Visit www.ecomposter.net for composting solutions.
