STC SC-2001L Quick Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SC-2001L/SC-2001R
Quick Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC-2001L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STC SC-2001L

Summary of Contents for STC SC-2001L

  • Page 1 SC-2001L/SC-2001R Quick Guide...

  • Page 2: Table Of Contents

    Table of Contents 1. Safety and Declaration of Conformity 1-1 Safety Considerations ------------------------------------------------------------------------------------- 1-2 Declaration of Conformity --------------------------------------------------------------------------------- 2. Instruction 2-1 Intended Use -------------------------------------------------------------------------------------------------- 2-2 Intended User Profile ---------------------------------------------------------------------------------------- 2-3 Intended Patient ---------------------------------------------------------------------------------------------- 2-4 Warning and Precaution ------------------------------------------------------------------------------------ 3. Name and Function of Each Parts -------------------------------------------------- 4.

  • Page 3: Safety And Declaration Of Conformity

    1. Safety and Declaration of Conformity 1-1 Safety Considerations This symbol reminds the user should read instruction/manual carefully before operating this device. This symbol cautions the user that important information regarding the operation and / or maintenance of this equipment has been included. Information preceded by this symbol should be read carefully to avoid damage to the equipment or miss operation.

  • Page 4: Intended Patient

    2-3 Intended Patient This product does not apply to children under 12 years old. 2-4 Warning and Precaution Do not use this device in explosive environments such as where flammable anesthetics exit or inside an oxygen chamber with strong electronic and electromagnetic fields e.g., mobile phones. l Warning Use only provided AC adapter and Type C/USB cable to charge this device.

  • Page 5: Name And Function Of Each Parts

    3. Name and Function of each Parts Dental Handpiece Cap...
  • Page 6 ✽The type C charger slot is compatible with the enclosed type C cable only. ✽✽The rechargeable battery is embedded and can only be replaced in authorized service center or dealer or distributor. ✽✽✽Do not replace the battery yourself or it may cause device damage and no warranty.

  • Page 7: Operation And Maintenance

    4. Operation and Maintenance 4-1 Quick Guide for Use Make sure the lens in front of the probe end is clean. Remove the Dental Handpiece Cap Connect the Dental Handpiece with cable Power on Press the Power button on the left side of top to turn on the device one time to turn on the device.
  • Page 8 Zoom in/out Touch Zoom in/out icon to adjust the zoom (x1, x1.5, x2) 400x400 Screen scale up 1. Touch the scale up icon to scale up the image 400x400 or 480x480 2. Touch the screen to disappear the icons. 480x480 Take Pictures Press snap button on the handle once for...
  • Page 9 Playback Touch on the home page. Select folder by touching screen. Touch or double click the folder to enter the folder to review the pictures or video. Touch for page up and down. Playback Preview Touch can preview the last 9 pictures, and for next 9 pictures.
  • Page 10 Set up: 1. Saturation adjustment 2. Contrast adjustment 3. Brightness adjustment 4. Language/Date/Time/Battery Saving/ Setting Reset set up 5. White Balance correction. Saturation: 1. Select to up or down level. 2. Enter Contrast: 1. Select to up or down level. 2.
  • Page 11 Language/Date/Time: 1. Battery Power saving mode 2. Date/Time 3. Language Selection (English/Simplified Chinese) 4. Setting Reset Power Saving Mode 1. Standby timing: After 1min or 5min or 10min without any operation and then screen and LED off automatically. 2. After 5min or 10min or 30min without any operation and then device shut down automatically.

  • Page 12: Pictures And Video Files Output By Connecting To A Pc

    Setting Reset: Press à to reset Saturation, Contrast, Brightness and Battery Saving to default. Turn off the device - Long press “Power” button - Power icon shown on the screen - Press “Power” button again and "Goodbye" displays on the LCD screen and release the button to turn off the device.

  • Page 13: Battery Charge

    4-3 Battery Charge When low battery shows on the LCD screen, get USB type C/A cable and AC adaptor plug in power outlet. An orange LED on the left top of the LCD screen will be lighted up after the USB type C/A cable inserts to the device. The battery has reached full capacity once the LED light turned off automatically.

  • Page 14: Care And Maintenance

    4-4 Care and Maintenance a. No calibration is needed. Even components exceed the life limitation, there is no aging problem. b. Clean the Dental Handpiece Putting the Dental Handpiece into “PBF” Sonacide Disinfectant (Glutaraldehyde 2%) for 10 minutes under 25℃ room temperature and cleaning by distilled water. After then, dipping the Dental Handpiece into 75% alcohol for 5 seconds.

  • Page 15: Troubleshooting Section

    Troubleshooting Section Problem Solution 5.1 Dental Handpiece does not connect with Make sure the direction red mark of cable and the cable properly handpiece each is at same direction 5.2 Micro SD card does not insert into the No functions but Preview function only device properly 5.3 Improper Operation Removing the SD card is not allowed during...

  • Page 16: Specifications

    Specifications ITEM DESCRIPTION Camera module Camera resolution CMOS sensor, 400 x 400 Frame Rate 30fps Light Source Lens Fixed Focus Field of View (FoV) 110° Lens F/No F 5.0± 5% Depth of Field (DoF) 5mm~50mm Control system Function Buttons Power / Snap / Record / Reset Output Interface SD card slot / USB2.0 Mass Storage Display...

  • Page 17: Electromagnetic Compatibility (Emc) Tables

    Electromagnetic Compatibility (EMC) Tables All medical electronic devices must conform to the requirements of IEC 60601-1-2. Precautions, adherences to the EMC guideline information provided in this manual and verification of all medical devices in simultaneous operation are required to ensure the electromagnetic compatibility and co-existence of all other medical devices.
  • Page 18 Floors should be wood, concrete or Contact: ±8kV Contact: ±8kV Electrostatic discharge ceramic tile. If floors are covered with synthetic material, the relative humidity Air: ±2kV, ±4kV,±8kV, ±15kV Air: ±8kV, ±15kV IEC 61000-4-2:2008 should be at least 30 %. Mains power quality should be that of a Electrical fast transient/ burst Input AC power ports: Input AC power ports: ±2kV...

  • Page 19: Warranty And Service Program

    Except in case of misuse, negligence, obvious abuse or accidental damage, if a material or manufacturing defect is discovered during the warranty period, repairs will be made without charge upon the return of the instrument to our distributor. Model No. SC-2001L/R Name: Address: __________________________________ Dealer’s Name: _______________________...

This manual is also suitable for:

Sc-2001r
