4.8A
Line up the four pro les L03B so the holes are at the same position.
Slide long side of connectors S20 and S08 into channel of pro le,
lining up holes as shown.
S20
L03B
S08
4.9A
Place pro les L03B and L03V onto pro les L07C and L01D. Line up holes as shown.
L07C
L03V
NOTE: ALL VIEWS ARE FROM INSIDE.
www.stcny.com
4.8B
Secure with three S02 screws. Repeat to make two sets.
S02
Pro le
#L03B
4.9B
L03B
L01D
Pro le
#L01D
L03B
Connector
QTY
#S02
2
#S20
Secure with six S02 screws.
L07C
L03B
L07C
L03V
L01D
Pro le
QTY
1
#L07C
30 of 57
S02
Connector
QTY
2
#S02
2
#S08
L07C
L03V
L03B
L01D
Screw
QTY
1
#S02
QTY
4
2
S02
QTY
6
