Assemble Sides

Place all the parts for the sides on a level surface.
Make sure the pieces are in the correct positions before assembling.
!
Carefully follow the order of assembly to ensure an easy installation.
Wear proper safety gear including work shoes, gloves and goggles.
!
You are assembling both sides in the following steps. Both sides are identical until step 6.1
4.1A
Line up the four pro les L03B so the holes are at the same position. Slide long side of connectors
S20 and S08 into channel of pro le, lining up holes as shown. Repeat for all four L03B pro les.
S20
S20
L03B
S08
4.2A
Place L03B onto pro les L07A and L01C. Line up holes as shown.
L07A
L01C
www.stcny.com
4.1B
S08
Pro le
L03B
Pro le
Secure with three S02 screws.
S02
Connector
QTY
#L03B 4
4.2B
Secure with three S02 screws.
Repeat to make two sets.
L07A
S02
Pro le
QTY
#L01C 2
27 of 55
L03B
Connector
QTY
#S02 4
#S20 4
S02
L01C
Screw
QTY
#L07A 2
S02
QTY
#S02 8
#S08 4
L07A
L03B
L01C
QTY
#S02 6
