4. Firmware and Software Description

4.4 SunSet Software (Service tool kit is necessary!)

4.4.1

Installation of SUNSET Software

4.4.2

Starting the SunSet Software

4-8 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1
This program enables the user to adjust the instrument:
•
Device configuration
•
Lamp adjust
•
Plate calibration
•
Measurement offsets
•
User configuration
The SunSet Software is installed using the following procedure:
•
Double click the setup icon to automatically install the SunSet software or
click the Start button on the lower taskbar and select <Run...> from the
menu and then browse for the correct setup file.
•
A series of dialog boxes will appear, read each one, enter any necessary
information and click Next to continue.
•
The files are then installed and the program icon is created.
•
When the Installation Complete dialog box appears, click Finish and
SunSet Software is operational.
• Perform the Sunset test with filter slide G or filter slide A.
• Filterslide G ensures that the entire
wavelength range is checked (340 - 750 nm)
• It is not possible to do the adjustments
with the Tuneable Wavelength filterslide.
If an instrument is already connected to one of Tecan's programs, close the
program or disconnect the instrument from the program.
To start the SunSet Software click the Start button on the lower taskbar and
select Programs and then TECAN –from the menus and select SunSet or click
the SunSet icon in the directory C:\Programme\Tecan\SunSet.
The following dialog box is displayed:
Select Connect from the Setup menu or press <Strg> and <F5> together to
connect the instrument.
Note:
