2. General
2.3.6

Temperature Control

2.3.7

Barcode Laser Scanner

2-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1
Peltier-based temperature control.
PARAMETERS
Temperature range:
Accuracy
Preheating time
sunrise
The specification of the temperature control unit (accuracy +/- 0.2°C)
applies if everything (reader, microplate, reagents, samples) has already target
temperature.
There is no specification for the heating up period and we are aware that within
this period not all wells are heated up equally. This effect will be seen especially
when reagents are not preheated.
During preheating the plate transport with a 96 well microplate loaded has to be
inside of the instrument. Only in this way a homogenous temperature is received
in the instrument. The microplate must not be the same as the one used for
measurement but should be clean to keep influences on the following
measurement low.
Every time the plate transport is moved it will take up to 1 min to reach again a
homogenous temperature inside of the instrument.
Bear in mind that if non-preheated microplate and/or reagents are added
temperature control will take a certain time depending on the temperature
difference between microplates.
LASER RADIATION – DO NOT STARE INTO THE BEAM!
The Class II / 2 Laser Scanner corresponds to the following norms:
•
DIN EN 60825-1 : 2001
•
CDRH 21 CFR 1040.10
PARAMETERS
Classification
Input power
Emission duration
Scan rate
Laser power
Definition of depth
Resolution
Min. print contrast
Ambient light
CHARACTERISTICS
Room temperature up to 42°C increments of 0.1°C
+/- 0.2°C
20 min.
WARNING
CLASS II / 2 LASER PRODUCT.
CHARACTERISTICS
Class II / 2 Laser Product
5 V DC +/- 10%
> 0.25 s
42 +/- 3 Scans / second (bi-directional)
< 1 mW
Max. 40 cm
0.15 cm
25% at 675 nm
Sun light: 40000 Lux
Halogen light: 1500 Lux
