Microplates - tecan sunrise RC Technical Manual

2.3.8

Microplates

2004-10 Technical Manual for sunrise RC, TW, TS, TC, BC, 6F No. T 137 302 Rev No. 1.1
Only 96-well format microplates (v-shaped, flat and round including strip-wells)
with transparent bottom can be used with the
PARAMETERS
Max. overall plate height
Diameter of wells
Pitch size (center to center)
Bottom shape
The barcode sticker has to be positioned on the right hand side of the plate,
7 mm from the front-right edge. The barcode may be up to 48 mm long.
A1
sunrise
The barcode reader supports the following barcode types:
•
CODE 39
•
Interleaved 2 of 5
•
UPC A, UPC E0, UPC E1
•
EAN8, EAN 13
•
Codabar
•
CODE 128
sunrise
Absorbance Reader.
CHARACTERISTICS
14.35 mm +/- 0.76 mm
(0.5650 inches +/- 0.0299 inches)
7.0 mm (0.276 inches)
9.0 mm (0.3543 inches)
V-shaped, Flat and Round bottom
6
55
7
2. General
2-11
