11 - 629510X1 Channel Buscard Replacement
• Follow instruction #1 for base plate removal.
• Unscrew the rear connector panel and slide the rear panel away from the console slightly to gain access to buscards.
• Unplug the two looms crossing over the top of the channel buscard and the loom connecting to the solo and cuts panel.
• The buscard is locked to the channel modules with four (six on later units) plastic retaining strips, clipping the card at each
corner.
ˆ 8S VIQSZI XLI GEVH TVIWW XLI XEFW SR X[S EHNEGIRX GPMTW ERH TYPP XLI GEVH YT[EVHW WPMKLXP] WS XLEX XLI GPMTW HS RSX PSGO
back in place, repeat for the remaining two clips.
• Lift the buscard clear and unplug the remaining looms.
ˆ )EVP] 1EXVM\ GSRWSPIW [IVI WLMTTIH [MXL E XIVQMREXMRK LIEHIV MRWIVXIH MR WSGOIX 40% SJ GLERRIP  ´W FYWGEVH -J ½XXIH
VIQSZI ERH ½X XS XLI VITPEGIQIRX GEVH
ˆ ;LIR ½XXMRK XLI VITPEGIQIRX FYWGEVH IRWYVI XLEX EPP JSYV PSGOMRK GPMTW EVI MR TPEGI ERH XLEX EPP GEVHW JYPP] MRWIVXIH
• Reconnect all cables.
