Chapter 1 - Setup

Matrix Rear Panel Connections

LINE IN 9-16
DAW RETURN 9-16
Audio Input/output
channels 9-16
5.1 Inputs
& Outputs
EXT1,2 (C, SW, LS, RS)
MON, MINI (C, SW, LS, RS)
CUE ST, FX OUT 1-4
2
Matrix 2 Owner's Manual
DEVICE SEND 9-16
CHANNEL OUT 9-16
DEVICE RETURN 9-16
0dBfs
switch
REC, MIX, CUE INS SEND
FX RETURNS 1-4 REC, MIX, CUE INS RTN
Master Section I/O
LINE IN 1-8
DAW RETURN 1-8
Foot-
X-Rack
switch
I/F
SW1 SW2 X-RACK / DIAG
+18dB
+24dB
RIGHT GAIN
LEFT T/HOLD
REC, MIX, FOLLOW MON OUT
VU TB MIC
Meter Master TB Mic
trim I/O trim
CHANNEL OUT 1-8
Audio Input/output
channels 1-8
SD memory card
USB
slot
Unused
Ethernet
USB GPIO SD CARD NETWORK
PUSH
IN - SPDIF - OUT
IN - AES - OUT
EXT 1,2 (L,R)
RIGHT - MINI - LEFT
MON L/R, ARTIST OUT
Mini LS Master
I/O
Power Input
DEVICE SEND 1-8
DEVICE RETURN 1-8
Digital I/O
Optical and AES
