Appendix B - Technical Specifications

Performance Figures
Headroom
Line In to Direct Out
Frequency Response
Noise
8,(
Line to Aux Bus Out
Frequency Response
Noise
8,(
Line To Mix/Rec Bus Out
Frequency Response
Noise
8,(
Matrix Console
Parameter
Width
Height
Depth
Weight
Heat Dissipation
Noise
Connector (DC power input)
Matrix Power Supply
Parameter
Width
Height
Depth
Weight
Heat Dissipation
Noise
Voltage
Current
Connector (mains input)
< +26dBu @ 1kHz (< 1% THD)
±0dB at 20Hz, +0/-0.1dB at 20kHz, -1dB at 80kHz
< -89dBu 20Hz - 22kHz
 $ O,^ H&Y O,^ ½PXIV
±0dB at 20Hz, +0/-0.1dB at 20kHz
< -93dBu (no channels routed)
< -76dBu (all channels routed, faders at 0dB)
 $ O,^ H&Y O,^ ½PXIV
±0dB at 20Hz, +0/-0.1dB at 20kHz
< -89dBu (no channels routed)
< -77.5dBu (all channels routed, faders at 0dB, pan at centre)
 $ O,^ H&Y O,^ ½PXIV
Value Unit
946 mm
228 mm
724 mm
25 kg
130 W
- -
BICC 12-pin Male
Value Unit
106 mm
202 mm
306 mm
5 kg
45 W
- -
100 - 240 V
2.0 - 1.0 A
IEC320 10A Male
Appendix B - Technical Specifications
Notes
MRGPYHMRK JIIX
I\GPYHMRK GSRRIGXSVW
ETTVS\MQEXIP]
fanless
Notes
MRGPYHMRK JIIX
I\GPYHMRK PIEH ERH GSRRIGXSVW
ETTVS\MQEXIP]
fanless
”
