44. Delta power shift

4. DPS in transmission

650
A. Changing the planet gears and recondi-
tioning planetary gear multi ---disc clutch
C3
1. Remove the DPS housing and the planetary gear on the
front surface of the reverse shuttle and remove bearing (1),
hub (4) and the cup springs and remove the disc pack, see
instr. A paragraphs 1---6 on page 444/1.
Note! The steel discs in this clutch (C3) are different com-
pared with the steel discs in clutches C1 and C2. The friction
discs, however, are the same as in other clutches.
Model
15. 5. 1996
2. Reconditioning the multi ---disc clutch C3 is done in the
same way as on transmissions 300 and 460.
3. Changing planet gears, see instr. A points 10 ---13 on page
444/2.
3. Assembling the planetary gear and fitting the gear and the
DPS housing onto the shuttle front face, see instr. 444 1A
points 19 ---26 on page 444/3.
795
Code Page
8050-- 8750 444 9
4
1
