Valtra 6000 Workshop Manual page 766

42. Gearbox
--- Set the required thickness (X) of shims into the bearing
location.
Note! First fit the shims with three lugs (0,30 mm, order no
30486400).
--- drive in the outer bearing race against the shims using ETV
893340.
5. Fit the transmisson shaft rear ball bearing with its circlip into
its location.
6. Place the assembled input shaft into the gearbox through
the side opening.
Note! The input shaft front bearing is fitted after the input shaft
and the layshaft are in place.
7. Fit the pump drive mechanism lowest bolt and tighten it to
a correct torque. Fit the S ---shaped lubricating oil pipe.
8. 11. 1990
s=0,05
0,10
0,30
0,50
8. Fit the layshaft (the bearings are fitted on the shaft). Raise
the input shaft for more space for layshaft.
9. Connect the S ---shaped lubricating oil feed pipe to the distri-
butor pipe on the bottom of the gearbox and connect the other
end to the hole on the gearbox wall (note o---ring). Fit the servo
valve block.
10. Fit the input shaft front bearing with ETV 892370. Fit the
bearing outer race.
46 Nm
11. Fit shims in front of the input shaft front bearing (select
2449
shims so that the bearings have a definite clearance). Tighten
the bearing cover.
Note! Try shims which were there before disassembling. Turn
the input shaft 20---30 revolutions, in order to bed in the bea-
rings.
713
Model Code Page
6000-- 8750 423
2448
9
2451
