83. Air conditioner
Technical data
Important! These instructions present both the earlier air conditioner (refrigerant R12) and the later air conditioner
which has refrigerant R134a (Suva). The compressor and the drier reservoir have markings stating which one of
the refrigerants is in the system. If R12 refrigerant is replaced with R134a, see page 831/10. Tractors which have
the earlier air conditioner, the heater and air conditioner control panel is fitted on the front side of the cab roof. On
the later air conditioner, the control panel is placed on the RH side of the cab roof.
Air conditioner on Valmet 6000-- 8750 tractors:
Refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- refrigerant filling in system
Compressor Diesel Kiki DKS 15 CH:
--- Number of cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- Cyl diam x stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- Max revs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- Lubricating oil if refrigerant R12
--- Lubricating oil if refrigerant R134a
--- Lubricating oil volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electro---magnetic clutch:
--- voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- starting torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- clutch clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Drier
--- heat fuse melts at (not heat fuse if refrigerant R134a)
Pressure switch switches off at max pressure, R12
Pressure switch switches off at max pressure, R134a
--- switches on again when pressure drops
Pressure switch switches off at min pressure
--- switches on again when pressure rises up to
Thermostatic switch:
--- switch off when evaporator temperature is below
--- switch on when evaporator temperature has risen up to (max cooling effect)
--- switch on when evaporator temperature has risen up to (min cooling effect)
High and low pressures at engine revs 1500 r/min between temperatures +20...+25 ˚C:
--- low pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
--- high pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1. 1. 1994
1. 4. 1997
. . . . . . . . . . . .
. . . . . . . . . . . .
1136
Model Code
6000-- 8750 830
R12 or R134a (SUVA)
1,4 kg
6 pcs
ø 34 mm x 24 mm
7000 r/min
Freol DS ---83P or Esso 2980
ZXL 100 PG (DH ---PS)
3
200 cm (2,0 dl)
12 V (DC)
50 Nm
44 W (max)
0,3 ---0,6 mm
+107...+118˚C
2,55±0,2 MPa
3,40±0,2 MPa
0,57±0,2 MPa
190±20 kPa
200±30 kPa
+2...+3 ˚C
+6...+7 ˚C
about +19 ˚C
50---300 kPa
700---1400 kPa
Page
2
