QUICK START
GUIDE
T SERIES
N SERIES
DIRECT
SmartTouch
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Valtra T Series

Summary of Contents for Valtra T Series

  • Page 1 QUICK START GUIDE T SERIES N SERIES DIRECT SmartTouch...

  • Page 2: Valtra Connect

    Direct help with suitable & fast solutions European IT security standards – Ask about retrofit Plan services in advance around seasonal peaks and maximise your uptime. For Valtra G, N and T Series machines. Check now if your machine is ready for Connect: get.agcoconnect.com...

  • Page 3: Table Of Contents

    Drive lever & Other controls ...... 7 SmartTouch terminal ........8 Settings screen symbols ......9 Drive display ..........10 This guide has been assembled to help Valtra operators to Driving modes ..........11 quickly become familiar with their tractor. Please note that Transmission settings .......12 this is NOT an operator’s manual.

  • Page 4: Smart A-Pillar Display

    T/N Series Quick Guide / Direct SMART A-PILLAR DISPLAY The brand new Valtra smart A-pillar display brings all the information you need to exactly where you need it. With the essential information always displayed up top in a clear and easy way you’ll never be left searching for what you need to know.
  • Page 5 T/N Series Quick Guide / Direct SMART A-PILLAR DISPLAY Use the wheel encoder and two buttons to navigate screen Via the settings menu select “Drive Display Mode” and select whether you want two, one or zero displays Using the encoder select the desired Drive Display and configure it to display the information you want The brightness of the A-pillar display can be adjusted via the left stalk.

  • Page 6: Smarttouch Armrest

    Valtra Guide engage ON/OFF Valve A (via quick couplers) QuickSteer engage Blue control lever for auxiliary hydraulics 28. Master activation (hydraulics, programmable buttons, Valtra Guide) Brown control lever for auxiliary hydraulics 29. Working lights main switch Green control lever for auxiliary hydraulics ON/OFF Valve B (e.g.

  • Page 7: Drive Lever & Other Controls

    T/N Series Quick Guide / Direct DRIVE OTHER LEVER CONTROLS Phone holder Emergency brake 3-pin current socket Memory button 1 3-pin current socket (optional) Memory button 2 SmartTouch Extend connector (optional) Speed range (ABCD) up ISOBUS terminal connector (optional) Speed range (ABCD) down Implement signal connector Rear lift (AutoControl): Lift / Stop / Lower / Float switch Button for fuel-operated heater (optional)

  • Page 8: Smarttouch Terminal

    T/N Series Quick Guide / Direct SMARTTOUCH TERMINAL The user interface has two sections: settings and drive displays. You can move between these sections with the Home (4) and Drive display (5) buttons. The settings have three levels: Home screen, setting screen and pop-ups.

  • Page 9: Settings Screen Symbols

    Suspension Hydraulics ISOBUS settings Armrest and Isobus AUX Hydraulics Rear power take-off Go to front screen Transmission Front power take-off Rear linkage Notes TaskDoc Front loader Reversible fan Calculator Valtra Guide AUTO Audio & Phone control Go to rear screen...

  • Page 10: Drive Display

    3. Go to settings screen 4. Active drive display 5. Visible drive displays Possible drive displays Transmission Front & rear hydraulics Front & rear PTO Rear lift Tractor health Memory button functions Safety camera Map (Valtra Guide) Counters ISOBUS implement terminal...

  • Page 11: Driving Modes

    T/N Series Quick Guide / Direct DRIVING MODES AUTOMATIC MODE When you start the tractor the automatic driving mode is automatically selected. There are two main ways of driving: • Pedal driving (no symbol on displays) • Lever driving (symbol on displays) You can control the driving speed with the drive pedal or the drive lever.

  • Page 12: Transmission Settings

    T/N Series Quick Guide / Direct TRANSMISSION SETTINGS Automatic slip regulation. Pre-programmed forward speed Automatic shifting between for drive lever mode. • OFF speed ranges C and D. • 1 = small influence Set value 0-max speed. • 5 = large influence Maximum speed.

  • Page 13: How To Adjust Transmission

    HOW TO ADJUST TRANSMISSION TO WORK BEST WAY POSSIBLE ON YOUR TASK Your Valtra tractor has features which allows the transmission to work the best way possible on every task. When you adjust transmission settings correctly, you will get lower fuel consumption and you will get power just to place where it is needed.

  • Page 14: A-B-C-D = Four Work Areas

    A-B-C-D = FOUR WORK AREAS Valtra continuously variable transmission (CVT) is truly a working machine. There are 4 working areas with 2 sweet spots per area, where transmission efficiency is over 90%. A total of 8 sweet spots is the highest amount in any...
  • Page 15 T/N Series Quick Guide / Direct HOW TO CHANGE SPEED RANGE TO CHANGE RANGE ABCD MANUALLY Simply push + or - button located on drive lever. TO CHANGE RANGE BETWEEN C AND D AUTOMATICALLY Select the transmission screen by pushing the transmission button.

  • Page 16: Ecopower Mode

    T/N Series Quick Guide / Direct ECOPOWER-MODE (ONLY ON MODELS N155ECO AND T175ECO) EcoPower is a Valtra innovation for more than 15 years. EcoPower-mode is designed especially for work that requires high torque, but not constant engine revs e.g. pulling work on the field.

  • Page 17: Cruise Control

    T/N Series Quick Guide / Direct CRUISE CONTROL Speed cruise control is controlled by the drive lever. It offers the possibility to maintain a steady speed. Push the drive lever to the right to engage cruise, hold for 2 seconds to store new speed.

  • Page 18: Engine Speed Memory

    T/N Series Quick Guide / Direct ENGINE SPEED MEMORY Valtra DIRECT has an Engine Speed memory that will keep engine RPM constant regardless of ground speed. Go to the engine screen with the engine button. You can easily preset Engine Speed memory 1 and 2: Change the value by selecting the appropriate memory and sliding it to the correct position or use the encoder wheel.

  • Page 19: Master Activation

    T/N Series Quick Guide / Direct MASTER ACTIVATION Hydraulics, steering valve, memory buttons and isobus aux can all be actived via the master activate button on the smarttouch armrest. When starting up the tractor simply press the button on the armrest and then select from the screen which functions you want to activate.

  • Page 20: Programmable Functions

    • Delete the current one-action programme. • Add new one-action programme. Programmable function examples: PTO start/stop Speed cruises (up to 4 speed cruise memories), Valtra Guide activation With different profiles you can easily change usage of TIP: Memory buttons according to your settings per profile.

  • Page 21: U-Pilot Headland Automatics

    T/N Series Quick Guide / Direct U-PILOT HEADLAND AUTOMATICS Open the Armrest screen. Tap the desired memory button. Tap the sequence icon. RECORD A U-PILOT PROGRAMME Tap the record icon. Perform the operations in the required order. Tap the record icon to end the recording. PROGRAM A U-PILOT PROGRAMME Tap add action icon.

  • Page 22: Programmable Functions - Hydraulics

    T/N Series Quick Guide / Direct PROGRAMMABLE FUNCTIONS HYDRAULICS There are totally 9 different programmable hydraulic controls in the SmartTouch armrest. The auxiliary hydraulic controls are positioned on the armrest. The joystick, fingertip levers and linear levers are programmable, thus you can select which lever controls which valve.

  • Page 23: Programmable Hydraulics

    T/N Series Quick Guide / Direct PROGRAMMABLE HYDRAULICS You have two ways to configurate your hydraulics and hydraulic controls with the SmartTouch armrest: 1. FROM MEMORY BUTTONS SETTING YOU CAN PROGRAM A VALVE TO ANY CONTROL Open the memory buttons setting. Select control you want to program.

  • Page 24: Hydraulic Settings

    T/N Series Quick Guide / Direct HYDRAULIC SETTINGS You can easily change between front and rear hydraulic setting view with just one swipe in the touch screen. Front valves Lock all valves The number of front valve Lock/unlock all valves and F for front and R for Rear valve from setting changes.

  • Page 25: Hydraulic Programming

    T/N Series Quick Guide / Direct HYDRAULIC PROGRAMMING VIA HYDRAULIC SETTINGS All settings per valve done via single pop-up. Swipe or tap functionality available. Valve settings locked Valve settings open Priority setting - Sets priority to ensure sufficient oil flow to the valve Flow rate of the + port Function selection of the + port x = no function active...

  • Page 26: Pick-Up Hitch And Linkage

    T/N Series Quick Guide / Direct PICK-UP HITCH AND LINKAGE TO UNLOCK THE PICK-UP HITCH Push the lifting button to fully raise the linkage. Pull the hitch latch lever to unlatch the hitch. Keep the lever pulled. Push the lowering button to lower the linkage. Release the hitch latch lever when the hitch has passed the locking latch.

  • Page 27: Rear Controls And Connections

    T/N Series Quick Guide / Direct REAR CONTROLS AND CONNECTIONS Front linkage shut-off valve (optional) Trailer coupling, Duo-Matic (optional) Trailer socket for trailer with ABS brakes Trailer coupling, 2-line system (optional) Trailer socket Quick coupling for air pressure devices (optional) Power outlet (12 V) ISOBUS connector (optional) Hydraulic levelling link (optional)

  • Page 28: Pto

    T/N Series Quick Guide / Direct You can use the power take-off (PTO) to transmit power from the tractor to an implement. Start the engine and tap the PTO symbol on the SmartTouch screen to open the PTO settings. Select the PTO speed. The value stays even in memory when you turn the ignition off.

  • Page 29: Auto Pto

    T/N Series Quick Guide / Direct AUTO PTO With the automatic power take-off (auto PTO), you can set the limits for the automatic start and stop of the PTO. You can give a different limit for when you lift the rear linkage or lower the rear linkage. The auto PTO controls the start and stop of the PTO in these conditions: •...

  • Page 30: Profile

    CREATE A PROFILE You can enter the profile settings from every terminal menu by tapping on the top bar. VALTRA is your default profile you cannot delete or change. Copy the default profile. Rename the new profile and modify the settings.

  • Page 31: Quicksteer

    T/N Series Quick Guide / Direct QUICKSTEER OPTIONAL QuickSteer is a steering system controlled by an electrohydraulic steering valve. The adjustable steering ratio gives you the possibility to alter the reaction speed between moving the steering wheel and the tractor turning which is helpful whenever the driver needs to steer a lot, for example when driving in a small yard or when doing front loader work.
  • Page 32 AGCO Valtra Inc. Valmetinkatu 2 Tel. +358 (0)2045 501 FI-44200 Suolahti www.valtra.com...
