4 How to Programme
4.4.14 14-** Special Functions
Par. Parameter description
No. #
14-0* Inverter Switching
14-00 Switching Pattern
14-01 Switching Frequency
14-03 Overmodulation
14-04 PWM Random
14-06 Dead Time Compensation
14-1* Mains On/Off
14-10 Mains Failure
14-11 Mains Voltage at Mains Fault
4
14-12 Function at Mains Imbalance
14-13 Mains Failure Step Factor
14-14 Kin. Backup Time Out
14-2* Trip Reset
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-24 Trip Delay at Current Limit
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-32 Current Lim Ctrl, Filter Time
14-35 Stall Protection
14-4* Energy Optimising
14-40 VT Level
14-41 AEO Minimum Magnetisation
14-42 Minimum AEO Frequency
14-43 Motor Cosphi
14-5* Environment
14-50 RFI Filter
14-51 DC Link Compensation
14-52 Fan Control
14-53 Fan Monitor
14-55 Output Filter
14-56 Capacitance Output Filter
14-57 Inductance Output Filter
14-59 Actual Number of Inverter Units
14-7* Compatibility
14-72 Legacy Alarm Word
14-73 Legacy Warning Word
14-74 Leg. Ext. Status Word
14-8* Options
14-80 Option Supplied by External 24VDC
14-9* Fault Settings
14-90 Fault Level
84
Default value 4-set-up
null All set-ups
null All set-ups
[1] On All set-ups
[0] Off All set-ups
[1] On All set-ups
[0] No function All set-ups
SR All set-ups
[0] Trip All set-ups
1.0 N/A All set-ups
60 s All set-ups
[0] Manual reset All set-ups
10 s All set-ups
[0] Normal operation All set-ups
null 2 set-ups
60 s All set-ups
60 s All set-ups
SR All set-ups
[0] No action All set-ups
0 N/A All set-ups
100 % All set-ups
0.020 s All set-ups
1.0 ms All set-ups
[1] Enabled All set-ups
66 % All set-ups
SR All set-ups
10 Hz All set-ups
SR All set-ups
[1] On 1 set-up
[1] On 1 set-up
[0] Auto All set-ups
[1] Warning All set-ups
[0] No Filter All set-ups
2.0 uF All set-ups
7.000 mH All set-ups
SR 1 set-up
0 N/A All set-ups
0 N/A All set-ups
0 N/A All set-ups
[1] Yes 2 set-ups
null 1 set-up
®
