4 How to Programme
1-20 Motor Power [kW]
Range:
Application [Application dependant]
dependent*
4
1-22 Motor Voltage
Range:
400. V* [10. - 1000. V]
1-23 Motor Frequency
Range:
Application [20 - 1000 Hz]
dependent*
1-24 Motor Current
Range:
7.20 A* [0.10 - 10000.00 A]
NB!
This parameter cannot be adjusted while the motor is running.
1-25 Motor Nominal Speed
Range:
1420. RPM* [100 - 60000 RPM]
NB!
This parameter cannot be adjusted while the motor is running.
5-12 Terminal 27 Digital Input
Option:
46
Function:
Enter the nominal motor power in kW according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running. This parameter is visible in LCP if
Regional Settings International
par. 0-03 is
NB!
Four sizes down, one size up from nominal unit rating.
Function:
Function:
Min - Max motor frequency: 20 - 1000 Hz.
Select the motor frequency value from the motor nameplate data. If a value different from 50 Hz
or 60 Hz is selected, it is necessary to adapt the load independent settings in par. 1-50
Magnetisation at Zero Speed
to par. 1-53
V motors, set the nameplate data for 230 V/50 Hz. Adapt par. 4-13
[RPM] Maximum Reference
and par. 3-03
Function:
Function:
Enter the nominal motor speed value from the motor nameplate data. This data is used for calcu-
lating automatic motor compensations.
Function:
Select the function from the available digital input range.
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC-brake inverse
Stop inverse
Start
®
