VLT AutomationDrive FC 300 Operating
Instructions
[84] SL Digital Output E
[85] SL Digital Output F
[120] Local reference active
[121] Remote reference active
[122] No alarm
[123] Start command active
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
5-40 Function Relay
Array [9]
(Relay 1 [0], Relay 2 [1], Relay 3 [2] (MCB 113), Relay 4 [3] (MCB 113), Relay 5 [4] (MCB 113), Relay 6 [5] (MCB 113), Relay 7 [6] (MCB 105), Relay
8 [7] (MCB 105), Relay 9 [8] (MCB 105))
Option:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
SL Controller Action
See par. 13-52
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [36]
dig. out. A low is executed.
See par. 13-52 SL Controller Action
Set dig. out. A high is executed. The input will go low whenever the Smart Logic Action [37]
dig. out. A low is executed.
Reference Site
Output is high when par. 3-13
Linked to hand auto at the same time as the LCP is in Hand on mode.
Reference site set in par. 3-13
Reference site: Local par. 3-13 [2]
Reference site: Remote par. 3-13 [1]
Reference site: Linked to Hand/ Auto
Hand
Hand -> off
Auto -> off
Auto
Reference Site = Remote
Output is high when par. 3-13
LCP is in [Auto on] mode. See above.
Output is high when no alarm is present.
Output is high when there is an active Start command (i.e. via digital input bus connection or [Hand
on] or [Auto on]), and no Stop or Start command is active.
Output is high when the frequency converter is running counter clockwise (the logical product of
the status bits 'running' AND 'reverse').
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Hand on]).
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Auto on]).
Function:
All digital and relay outputs are default set to "No Operation".
The control card is ready. E.g.: Feedback from a drive where the control is supplied by an external
24 V (MCB107) and the main power to drive is not detected.
Drive is ready to operate. Mains and control supplies are OK.
The frequency converter is ready for operation and is in Auto On mode
Ready for operation. No start or stop commands have been applied (start/disable). No warnings are
active.
Motor is running, and shaft torque present.
Output speed is higher than the speed set in par. 1-81 Min Speed for Function at Stop [RPM]. The
motor is running and no warnings.
Motor is running within the programmed current and speed ranges set in par. 4-50
Low Warning Speed High
and par. 4-53
Motor runs at reference speed. No warnings.
An alarm activates the output. No warnings
®
MG.33.AG.02 - VLT is a registered Danfoss trademark
. The input will go high whenever the Smart Logic Action [42]
. The input will go high whenever the Smart Logic Action [43]
= [2] Local or when par. 3-13
Local reference
active [120]
1
0
1
1
0
0
Linked to hand/auto
[1] or
. No warnings.
4 How to Programme
Set
Set
Reference Site
= [0]
Remote reference
active [121]
4
0
1
0
0
0
1
[0] while the
Warning Current
65
