4 How to Programme
4.4.7 6-** Analog In/Out
Par. Parameter description
No. #
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
6-1* Analog Input 1
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-12 Terminal 53 Low Current
6-13 Terminal 53 High Current
6-14 Terminal 53 Low Ref./Feedb. Value
4
6-15 Terminal 53 High Ref./Feedb. Value
6-16 Terminal 53 Filter Time Constant
6-2* Analog Input 2
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-22 Terminal 54 Low Current
6-23 Terminal 54 High Current
6-24 Terminal 54 Low Ref./Feedb. Value
6-25 Terminal 54 High Ref./Feedb. Value
6-26 Terminal 54 Filter Time Constant
6-3* Analog Input 3
6-30 Terminal X30/11 Low Voltage
6-31 Terminal X30/11 High Voltage
6-34 Term. X30/11 Low Ref./Feedb. Value
6-35 Term. X30/11 High Ref./Feedb. Value
6-36 Term. X30/11 Filter Time Constant
6-4* Analog Input 4
6-40 Terminal X30/12 Low Voltage
6-41 Terminal X30/12 High Voltage
6-44 Term. X30/12 Low Ref./Feedb. Value
6-45 Term. X30/12 High Ref./Feedb. Value
6-46 Term. X30/12 Filter Time Constant
6-5* Analog Output 1
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
6-53 Terminal 42 Output Bus Control
6-54 Terminal 42 Output Timeout Preset
6-55 Analog Output Filter
6-6* Analog Output 2
6-60 Terminal X30/8 Output
6-61 Terminal X30/8 Min. Scale
6-62 Terminal X30/8 Max. Scale
6-63 Terminal X30/8 Bus Control
6-64 Terminal X30/8 Output Timeout Preset
6-7* Analog Output 3
6-70 Terminal X45/1 Output
6-71 Terminal X45/1 Min. Scale
6-72 Terminal X45/1 Max. Scale
6-73 Terminal X45/1 Bus Control
6-74 Terminal X45/1 Output Timeout Preset
6-8* Analog Output 4
6-80 Terminal X45/3 Output
6-81 Terminal X45/3 Min. Scale
6-82 Terminal X45/3 Max. Scale
6-83 Terminal X45/3 Bus Control
6-84 Terminal X45/3 Output Timeout Preset
78
Default value 4-set-up
10 s All set-ups
[0] Off All set-ups
0.07 V All set-ups
10.00 V All set-ups
0.14 mA All set-ups
20.00 mA All set-ups
0 ReferenceFeedbackUnit All set-ups
SR All set-ups
0.001 s All set-ups
0.07 V All set-ups
10.00 V All set-ups
0.14 mA All set-ups
20.00 mA All set-ups
0 ReferenceFeedbackUnit All set-ups
SR All set-ups
0.001 s All set-ups
0.07 V All set-ups
10.00 V All set-ups
0 ReferenceFeedbackUnit All set-ups
SR All set-ups
0.001 s All set-ups
0.07 V All set-ups
10.00 V All set-ups
0 ReferenceFeedbackUnit All set-ups
SR All set-ups
0.001 s All set-ups
null All set-ups
0.00 % All set-ups
100.00 % All set-ups
0.00 % All set-ups
0.00 % 1 set-up
[0] Off 1 set-up
null All set-ups
0.00 % All set-ups
100.00 % All set-ups
0.00 % All set-ups
0.00 % 1 set-up
null All set-ups
0.00 % All set-ups
100.00 % All set-ups
0.00 % All set-ups
0.00 % 1 set-up
null All set-ups
0.00 % All set-ups
100.00 % All set-ups
0.00 % All set-ups
0.00 % 1 set-up
®
MG.33.AG.02 - VLT is a registered Danfoss trademark
®
VLT AutomationDrive FC 300 Operating
FC 302 Change dur- Conver-
only ing opera- sion index
tion
TRUE 0
TRUE -
TRUE -2
TRUE -2
TRUE -5
TRUE -5
TRUE -3
TRUE -3
TRUE -3
TRUE -2
TRUE -2
TRUE -5
TRUE -5
TRUE -3
TRUE -3
TRUE -3
TRUE -2
TRUE -2
TRUE -3
TRUE -3
TRUE -3
TRUE -2
TRUE -2
TRUE -3
TRUE -3
TRUE -3
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
TRUE -
TRUE -2
TRUE -2
TRUE -2
TRUE -2
