4 How to Programme
4.4.3 2-** Brakes
Par. Parameter description
No. #
2-0* DC-Brake
2-00 DC Hold Current
2-01 DC Brake Current
2-02 DC Braking Time
2-03 DC Brake Cut In Speed [RPM]
2-04 DC Brake Cut In Speed [Hz]
2-05 Maximum Reference
2-1* Brake Energy Funct.
2-10 Brake Function
4
2-11 Brake Resistor (ohm)
2-12 Brake Power Limit (kW)
2-13 Brake Power Monitoring
2-15 Brake Check
2-16 AC brake Max. Current
2-17 Over-voltage Control
2-18 Brake Check Condition
2-19 Over-voltage Gain
2-2* Mechanical Brake
2-20 Release Brake Current
2-21 Activate Brake Speed [RPM]
2-22 Activate Brake Speed [Hz]
2-23 Activate Brake Delay
2-24 Stop Delay
2-25 Brake Release Time
2-26 Torque Ref
2-27 Torque Ramp Time
2-28 Gain Boost Factor
74
Default value 4-set-up
50 % All set-ups
50 % All set-ups
10.0 s All set-ups
SR All set-ups
SR All set-ups
MaxReference (P303) All set-ups
null All set-ups
SR All set-ups
SR All set-ups
[0] Off All set-ups
[0] Off All set-ups
100.0 % All set-ups
[0] Disabled All set-ups
[0] At Power Up All set-ups
100 % All set-ups
ImaxVLT (P1637) All set-ups
SR All set-ups
SR All set-ups
0.0 s All set-ups
0.0 s All set-ups
0.20 s All set-ups
0.00 % All set-ups
0.2 s All set-ups
1.00 N/A All set-ups
®
